5N8U | pdb_00005n8u

Crystal Structure of Drosophila DHX36 helicase in complex with CTCTCCT

• PDB DOI: https://doi.org/10.2210/pdb5N8U/pdb
• NAKB: 5N8U

• Classification: HYDROLASE
• Organism(s): Drosophila melanogaster, Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-02-24 Released: 2018-03-14
• Deposition Author(s): Chen, W.-F., Rety, S., Guo, H.-L., Wu, W.-Q., Liu, N.-N., Liu, Q.-W., Dai, Y.-X., Xi, X.-G.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.62 Å
• R-Value Free:
  0.249 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.182 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.186 (Depositor)

Starting Model: experimental

Literature

Structural and mechanistic insights into DHX36-mediated innate immunity and G-quadruplex unfolding

Chen, W.-F., Rety, S., Guo, H.-L., Wu, W.-Q., Liu, N.-N., Liu, Q.-W., Dai, Y.-X., Xi, X.-G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Biological Assembly Evidence: SAXS

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 221.62 kDa
• Atom Count: 14,110
• Modeled Residue Count: 1,714
• Deposited Residue Count: 1,904
• Unique protein chains: 1
• Unique nucleic acid chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CG9323, isoform A	A, B	944	Drosophila melanogaster	Mutation(s): 0  Gene Names: CG9323, Dmel_CG9323 EC: 3.6.1.3 (PDB Primary Data), 3.6.4.13 (UniProt)
UniProt
Find proteins for Q8SWT2 (Drosophila melanogaster) Explore Q8SWT2  Go to UniProtKB:  Q8SWT2

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(P*CP*TP*CP*TP*CP*CP*CP*T)-3')	C, D	8	Homo sapiens

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	E [auth A], F [auth B]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.62 Å
• R-Value Free:  0.249 (Depositor), 0.250 (DCC)
• R-Value Work:  0.182 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.186 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 302.368	α = 90
b = 51.288	β = 114.7
c = 164.097	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-03-14
Deposition Author(s): Chen, W.-F., Rety, S., Guo, H.-L., Wu, W.-Q., Liu, N.-N., Liu, Q.-W., Dai, Y.-X., Xi, X.-G.

Revision History

• Version 1.0: 2018-03-14
  Type: Initial release

• Version 1.1: 2024-01-17
  Changes: Data collection, Database references, Refinement description
