5N60

Cryo-EM structure of RNA polymerase I in complex with Rrn3 and Core Factor (Orientation I)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural Basis of RNA Polymerase I Transcription Initiation.

Engel, C.Gubbey, T.Neyer, S.Sainsbury, S.Oberthuer, C.Baejen, C.Bernecky, C.Cramer, P.

(2017) Cell 169: 120-131.e22

  • DOI: 10.1016/j.cell.2017.03.003
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Transcription initiation at the ribosomal RNA promoter requires RNA polymerase (Pol) I and the initiation factors Rrn3 and core factor (CF). Here, we combine X-ray crystallography and cryo-electron microscopy (cryo-EM) to obtain a molecular model for ...

    Transcription initiation at the ribosomal RNA promoter requires RNA polymerase (Pol) I and the initiation factors Rrn3 and core factor (CF). Here, we combine X-ray crystallography and cryo-electron microscopy (cryo-EM) to obtain a molecular model for basal Pol I initiation. The three-subunit CF binds upstream promoter DNA, docks to the Pol I-Rrn3 complex, and loads DNA into the expanded active center cleft of the polymerase. DNA unwinding between the Pol I protrusion and clamp domains enables cleft contraction, resulting in an active Pol I conformation and RNA synthesis. Comparison with the Pol II system suggests that promoter specificity relies on a distinct "bendability" and "meltability" of the promoter sequence that enables contacts between initiation factors, DNA, and polymerase.


    Organizational Affiliation

    Department of Molecular Biology, Max Planck Institute for Biophysical Chemistry, Am Fassberg 11, 37077 Göttingen, Germany. Electronic address: patrick.cramer@mpibpc.mpg.de.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA190A1664Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA190RPA1RRN1YOR341WO6276
EC: 2.7.7.6
Find proteins for P10964 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P10964
Go to UniProtKB:  P10964
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA135B1203Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA135RPA2RRN2SRP3YPR010CYP9531.03C
EC: 2.7.7.6
Find proteins for P22138 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P22138
Go to UniProtKB:  P22138
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA14D137Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA14YDR156WYD8358.11
Find proteins for P50106 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P50106
Go to UniProtKB:  P50106
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA12I125Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA12RRN4YJR063WJ1747
Find proteins for P32529 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32529
Go to UniProtKB:  P32529
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I and III subunit RPAC2K142Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPC19YNL113WN1937
Find proteins for P28000 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P28000
Go to UniProtKB:  P28000
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC4L70Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPC10RPB12YHR143W-AYHR143BW
Find proteins for P40422 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40422
Go to UniProtKB:  P40422
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA49M415Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA49RRN13YNL248CN0880
Find proteins for Q01080 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q01080
Go to UniProtKB:  Q01080
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA34N233Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA34YJL148WJ0637
Find proteins for P47006 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47006
Go to UniProtKB:  P47006
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
RNA polymerase I-specific transcription initiation factor RRN3O627Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRN3YKL125W
Find proteins for P36070 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P36070
Go to UniProtKB:  P36070
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
RNA polymerase I-specific transcription initiation factor RRN6P894Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRN6YBL014CYBL0311YBL0312
Find proteins for P32786 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32786
Go to UniProtKB:  P32786
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
RNA polymerase I-specific transcription initiation factor RRN11R507Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRN11YML043CYM9827.09C
Find proteins for Q04712 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q04712
Go to UniProtKB:  Q04712
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC5J70Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPB10YOR210W
Find proteins for P22139 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P22139
Go to UniProtKB:  P22139
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
RNA polymerase I-specific transcription initiation factor RRN7Q514Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RRN7YJL025WJ1273
Find proteins for P40992 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40992
Go to UniProtKB:  P40992
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I and III subunit RPAC1C335Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPC40RPC5YPR110CP8283.18
Find proteins for P07703 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P07703
Go to UniProtKB:  P07703
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC1E215Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPB5RPA7RPC9YBR154CYBR1204
Find proteins for P20434 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20434
Go to UniProtKB:  P20434
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC2F155Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPO26RPB6YPR187WP9677.8
Find proteins for P20435 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20435
Go to UniProtKB:  P20435
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA43G326Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPA43RRN12YOR340CO6271
Find proteins for P46669 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P46669
Go to UniProtKB:  P46669
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC3H146Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: RPB8YOR224CYOR50-14
Find proteins for P20436 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20436
Go to UniProtKB:  P20436
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download CCD File
A, B, I, J, L, Q
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanySFB860, SPP1935
The Advanced Grant TRANSREGULON from the European Research CouncilGermany693023
Volkswagen FoundationGermany--

Revision History

  • Version 1.0: 2017-04-05
    Type: Initial release
  • Version 1.1: 2017-04-12
    Changes: Structure summary
  • Version 1.2: 2017-09-06
    Changes: Author supporting evidence, Data collection
  • Version 1.3: 2018-10-03
    Changes: Advisory, Data collection, Derived calculations
