5MEA

Crystal structure of yeast Cdt1 (N terminal and middle domain), form 2.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.203
  • R-Value Observed: 0.206

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Cdt1 stabilizes an open MCM ring for helicase loading.

Frigola, J.He, J.Kinkelin, K.Pye, V.E.Renault, L.Douglas, M.E.Remus, D.Cherepanov, P.Costa, A.Diffley, J.F.X.

(2017) Nat Commun 8: 15720-15720

  • DOI: https://doi.org/10.1038/ncomms15720
  • Primary Citation of Related Structures:
    5ME9, 5MEA, 5MEB, 5MEC

  • PubMed Abstract:

    ORC, Cdc6 and Cdt1 act together to load hexameric MCM, the motor of the eukaryotic replicative helicase, into double hexamers at replication origins. Here we show that Cdt1 interacts with MCM subunits Mcm2, 4 and 6, which both destabilizes the Mcm2-5 interface and inhibits MCM ATPase activity. Using X-ray crystallography, we show that Cdt1 contains two winged-helix domains in the C-terminal half of the protein and a catalytically inactive dioxygenase-related N-terminal domain, which is important for MCM loading, but not for subsequent replication. We used these structures together with single-particle electron microscopy to generate three-dimensional models of MCM complexes. These show that Cdt1 stabilizes MCM in a left-handed spiral open at the Mcm2-5 gate. We propose that Cdt1 acts as a brace, holding MCM open for DNA entry and bound to ATP until ORC-Cdc6 triggers ATP hydrolysis by MCM, promoting both Cdt1 ejection and MCM ring closure.


  • Organizational Affiliation

    Chromosome Replication Laboratory, The Francis Crick Institute, 1 Midland Road, London NW1 1AT, UK.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cell division cycle protein CDT1439Saccharomyces cerevisiaeMutation(s): 0
Gene Names: TAH11CDT1SID2YJR046WJ1641
UniProt
Find proteins for P47112 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47112
Go to UniProtKB:  P47112
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47112
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.203
  • R-Value Observed: 0.206
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.51α = 90
b = 89.35β = 90
c = 121.91γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-05-17
    Type: Initial release
  • Version 1.1: 2017-07-05
    Changes: Database references
