5M6A

Crystal structure of cardiotoxic Bence-Jones light chain dimer H9


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.64 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.183

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Concurrent structural and biophysical traits link with immunoglobulin light chains amyloid propensity.

Oberti, L.Rognoni, P.Barbiroli, A.Lavatelli, F.Russo, R.Maritan, M.Palladini, G.Bolognesi, M.Merlini, G.Ricagno, S.

(2017) Sci Rep 7: 16809-16809

  • DOI: 10.1038/s41598-017-16953-7
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Light chain amyloidosis (AL), the most common systemic amyloidosis, is caused by the overproduction and the aggregation of monoclonal immunoglobulin light chains (LC) in target organs. Due to genetic rearrangement and somatic hypermutation, virtually ...

    Light chain amyloidosis (AL), the most common systemic amyloidosis, is caused by the overproduction and the aggregation of monoclonal immunoglobulin light chains (LC) in target organs. Due to genetic rearrangement and somatic hypermutation, virtually, each AL patient presents a different amyloidogenic LC. Because of such complexity, the fine molecular determinants of LC aggregation propensity and proteotoxicity are, to date, unclear; significantly, their decoding requires investigating large sets of cases. Aiming to achieve generalizable observations, we systematically characterised a pool of thirteen sequence-diverse full length LCs. Eight amyloidogenic LCs were selected as responsible for severe cardiac symptoms in patients; five non-amyloidogenic LCs were isolated from patients affected by multiple myeloma. Our comprehensive approach (consisting of spectroscopic techniques, limited proteolysis, and X-ray crystallography) shows that low fold stability and high protein dynamics correlate with amyloidogenic LCs, while hydrophobicity, structural rearrangements and nature of the LC dimeric association interface (as observed in seven crystal structures here presented) do not appear to play a significant role in defining amyloid propensity. Based on the structural and biophysical data, our results highlight shared properties driving LC amyloid propensity, and these data will be instrumental for the design of synthetic inhibitors of LC aggregation.


    Organizational Affiliation

    Dipartimento di Bioscienze, Università degli Studi di Milano, 20133, Milano, Italy.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Bence-Jones light chain
A, B, C, D
216N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PO4
Query on PO4

Download SDF File
Download CCD File
A, B, D
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A, B, C, D
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.64 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.183
  • Space Group: P 1
Unit Cell:
Length (Å)Angle (°)
a = 46.492α = 95.32
b = 63.429β = 85.84
c = 86.637γ = 99.58
Software Package:
Software NamePurpose
XDSdata reduction
BUSTERrefinement
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-11-15
    Type: Initial release
  • Version 1.1: 2017-12-13
    Type: Database references
