5M64

RNA Polymerase I elongation complex with A49 tandem winged helix domain


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.6 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Molecular Structures of Transcribing RNA Polymerase I.

Tafur, L.Sadian, Y.Hoffmann, N.A.Jakobi, A.J.Wetzel, R.Hagen, W.J.Sachse, C.Muller, C.W.

(2016) Mol. Cell 64: 1135-1143

  • DOI: 10.1016/j.molcel.2016.11.013
  • Primary Citation of Related Structures:  5M5W, 5M5X, 5M5Y

  • PubMed Abstract:
  • RNA polymerase I (Pol I) is a 14-subunit enzyme that solely synthesizes pre-ribosomal RNA. Recently, the crystal structure of apo Pol I gave unprecedented insight into its molecular architecture. Here, we present three cryo-EM structures of elongatin ...

    RNA polymerase I (Pol I) is a 14-subunit enzyme that solely synthesizes pre-ribosomal RNA. Recently, the crystal structure of apo Pol I gave unprecedented insight into its molecular architecture. Here, we present three cryo-EM structures of elongating Pol I, two at 4.0 Å and one at 4.6 Å resolution, and a Pol I open complex at 3.8 Å resolution. Two modules in Pol I mediate the narrowing of the DNA-binding cleft by closing the clamp domain. The DNA is bound by the clamp head and by the protrusion domain, allowing visualization of the upstream and downstream DNA duplexes in one of the elongation complexes. During formation of the Pol I elongation complex, the bridge helix progressively folds, while the A12.2 C-terminal domain is displaced from the active site. Our results reveal the conformational changes associated with elongation complex formation and provide additional insight into the Pol I transcription cycle.


    Organizational Affiliation

    European Molecular Biology Laboratory (EMBL), Structural and Computational Biology Unit, Meyerhofstrasse 1, 69117 Heidelberg, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA190
A
1664Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA190 (RPA1, RRN1)
EC: 2.7.7.6
Find proteins for P10964 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P10964
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA135
B
1203Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA135 (RPA2, RRN2, SRP3)
EC: 2.7.7.6
Find proteins for P22138 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P22138
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I and III subunit RPAC1
C
335Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPC40 (RPC5)
Find proteins for P07703 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P07703
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA14
D
137Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA14
Find proteins for P50106 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P50106
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC1
E
215Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB5 (RPA7, RPC9)
Find proteins for P20434 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20434
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC2
F
155Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPO26 (RPB6)
Find proteins for P20435 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20435
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA43
G
326Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA43 (RRN12)
Find proteins for P46669 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P46669
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC3
H
146Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB8
Find proteins for P20436 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20436
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA12
I
125Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA12 (RRN4)
Find proteins for P32529 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P32529
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC5
J
70Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB10
Find proteins for P22139 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P22139
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I and III subunit RPAC2
K
142Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPC19
Find proteins for P28000 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P28000
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC4
L
70Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPC10 (RPB12)
Find proteins for P40422 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40422
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA49
M
415Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA49 (RRN13)
Find proteins for Q01080 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q01080
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase I subunit RPA34
N
233Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPA34
Find proteins for P47006 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P47006
Entity ID: 15
MoleculeChainsLengthOrganism
Non-template DNAS70Saccharomyces cerevisiae
Entity ID: 16
MoleculeChainsLengthOrganism
Template DNAT70Saccharomyces cerevisiae
Entity ID: 17
MoleculeChainsLengthOrganism
RNAR10Saccharomyces cerevisiae
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, I, J, L
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.6 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationCountryGrant Number
European Research CouncilGermanyERC-2013-AdG340964-POL1PIC

Revision History

  • Version 1.0: 2016-12-21
    Type: Initial release
  • Version 1.1: 2016-12-28
    Type: Database references
  • Version 1.2: 2017-08-30
    Type: Author supporting evidence, Derived calculations, Experimental preparation
