5LGY

Lysine 120-acetylated P53 DNA binding domain in a complex with the BAX response element.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.92 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.238

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural Basis for p53 Lys120-Acetylation-Dependent DNA-Binding Mode.

Vainer, R.Cohen, S.Shahar, A.Zarivach, R.Arbely, E.

(2016) J.Mol.Biol. 428: 3013-3025

  • DOI: 10.1016/j.jmb.2016.06.009
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Normal cellular homeostasis depends on tight regulation of gene expression, which requires the modulation of transcription factors' DNA-binding specificity. That said, the mechanisms that allow transcription factors to distinguish between closely rel ...

    Normal cellular homeostasis depends on tight regulation of gene expression, which requires the modulation of transcription factors' DNA-binding specificity. That said, the mechanisms that allow transcription factors to distinguish between closely related response elements following different cellular signals are not fully understood. In the tumor suppressor protein p53, acetylation of loop L1 residue Lys120 within the DNA-binding domain has been shown to promote the transcription of proapoptotic genes such as bax. Here, we report the crystal structures of Lys120-acetylated p53 DNA-binding domain in complex with a consensus response element and with the natural BAX response element. Our structural analyses reveal that Lys120 acetylation expands the conformational space of loop L1 in the DNA-bound state. Loop L1 flexibility is known to increase p53's DNA-binding specificity, and Lys120-acetylation-dependent conformational changes in loop L1 enable the formation of sequence-dependent DNA-binding modes for p53. Furthermore, binding to the natural BAX response element is accompanied by global conformational changes, deformation of the DNA helical structure, and formation of an asymmetric tetrameric complex. Based on these findings, we suggest a model for p53's Lys120 acetylation-dependent DNA-binding mode.


    Organizational Affiliation

    Department of Chemistry, Ben-Gurion University of the Negev, Beer-Sheva, 84105, Israel.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Cellular tumor antigen p53
A, B, C, D
198Homo sapiensMutation(s): 0
Gene Names: TP53 (P53)
Find proteins for P04637 (Homo sapiens)
Go to Gene View: TP53
Go to UniProtKB:  P04637
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(*TP*CP*AP*CP*AP*AP*GP*TP*TP*AP*GP*AP*GP*AP*CP*AP*AP*GP*CP*CP*T)-3')E21synthetic construct
Entity ID: 3
MoleculeChainsLengthOrganism
DNA (5'-D(*AP*GP*GP*CP*TP*TP*GP*TP*CP*TP*CP*TP*AP*AP*CP*TP*TP*GP*TP*GP*A)-3')F21synthetic construct
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, C, D
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
ALY
Query on ALY
A, B, C, D
L-PEPTIDE LINKINGC8 H16 N2 O3LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.92 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.238
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 67.703α = 90.00
b = 70.344β = 95.83
c = 104.995γ = 90.00
Software Package:
Software NamePurpose
XDSdata scaling
PHENIXrefinement
PHASERphasing
XDSdata reduction
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2016-07-08
  • Released Date: 2016-07-27
  • Deposition Author(s): Arbely, E., Vainer, R.
  • This entry supersedes: 5BUB

Funding OrganizationLocationGrant Number
Concern FoundationUnited States--

Revision History

  • Version 1.0: 2016-07-27
    Type: Initial release
  • Version 1.1: 2016-08-17
    Type: Database references
