5L3P

Cryo-EM structure of stringent response factor RelA bound to ErmCL-stalled ribosome complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

The stringent factor RelA adopts an open conformation on the ribosome to stimulate ppGpp synthesis.

Arenz, S.Abdelshahid, M.Sohmen, D.Payoe, R.Starosta, A.L.Berninghausen, O.Hauryliuk, V.Beckmann, R.Wilson, D.N.

(2016) Nucleic Acids Res 44: 6471-6481

  • DOI: 10.1093/nar/gkw470
  • Primary Citation of Related Structures:
    5L3P

  • PubMed Abstract:
  • Under stress conditions, such as nutrient starvation, deacylated tRNAs bound within the ribosomal A-site are recognized by the stringent factor RelA, which converts ATP and GTP/GDP to (p)ppGpp. The signaling molecules (p)ppGpp globally rewire the cellular transcriptional program and general metabolism, leading to stress adaptation ...

    Under stress conditions, such as nutrient starvation, deacylated tRNAs bound within the ribosomal A-site are recognized by the stringent factor RelA, which converts ATP and GTP/GDP to (p)ppGpp. The signaling molecules (p)ppGpp globally rewire the cellular transcriptional program and general metabolism, leading to stress adaptation. Despite the additional importance of the stringent response for regulation of bacterial virulence, antibiotic resistance and persistence, structural insight into how the ribosome and deacylated-tRNA stimulate RelA-mediated (p)ppGpp has been lacking. Here, we present a cryo-EM structure of RelA in complex with the Escherichia coli 70S ribosome with an average resolution of 3.7 Å and local resolution of 4 to >10 Å for RelA. The structure reveals that RelA adopts a unique 'open' conformation, where the C-terminal domain (CTD) is intertwined around an A/T-like tRNA within the intersubunit cavity of the ribosome and the N-terminal domain (NTD) extends into the solvent. We propose that the open conformation of RelA on the ribosome relieves the autoinhibitory effect of the CTD on the NTD, thus leading to stimulation of (p)ppGpp synthesis by RelA.


    Organizational Affiliation

    Gene Center and Department for Biochemistry, University of Munich, Munich 81377, Germany Center for integrated Protein Science Munich (CiPSM), University of Munich, Munich 81377, Germany wilson@lmb.uni-muenchen.de.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L2 D273Escherichia coli K-12Mutation(s): 0
Gene Names: rplBb3317JW3279
Find proteins for P60422 (Escherichia coli (strain K12))
Explore P60422
Go to UniProtKB:  P60422
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L3 E209Escherichia coli K-12Mutation(s): 0
Gene Names: rplCb3320JW3282
Find proteins for P60438 (Escherichia coli (strain K12))
Explore P60438
Go to UniProtKB:  P60438
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L4 F201Escherichia coli K-12Mutation(s): 0
Gene Names: rplDeryAb3319JW3281
Find proteins for P60723 (Escherichia coli (strain K12))
Explore P60723
Go to UniProtKB:  P60723
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L5 G179Escherichia coli K-12Mutation(s): 0
Gene Names: rplEb3308JW3270
Find proteins for P62399 (Escherichia coli (strain K12))
Explore P62399
Go to UniProtKB:  P62399
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L6 H177Escherichia coli K-12Mutation(s): 0
Gene Names: rplFb3305JW3267
Find proteins for P0AG55 (Escherichia coli (strain K12))
Explore P0AG55
Go to UniProtKB:  P0AG55
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L9 I149Escherichia coli K-12Mutation(s): 0
Gene Names: rplIb4203JW4161
Find proteins for P0A7R1 (Escherichia coli (strain K12))
Explore P0A7R1
Go to UniProtKB:  P0A7R1
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L13 N142Escherichia coli K-12Mutation(s): 0
Gene Names: rplMb3231JW3200
Find proteins for P0AA10 (Escherichia coli (strain K12))
Explore P0AA10
Go to UniProtKB:  P0AA10
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L14 O123Escherichia coli K-12Mutation(s): 0
Gene Names: rplNb3310JW3272
Find proteins for P0ADY3 (Escherichia coli (strain K12))
Explore P0ADY3
Go to UniProtKB:  P0ADY3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L15 P144Escherichia coli K-12Mutation(s): 0
Gene Names: rplOb3301JW3263
Find proteins for P02413 (Escherichia coli (strain K12))
Explore P02413
Go to UniProtKB:  P02413
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L16 Q136Escherichia coli K-12Mutation(s): 0
Gene Names: rplPb3313JW3275
Find proteins for P0ADY7 (Escherichia coli (strain K12))
Explore P0ADY7
Go to UniProtKB:  P0ADY7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L17 R127Escherichia coli K-12Mutation(s): 0
Gene Names: rplQb3294JW3256
Find proteins for P0AG44 (Escherichia coli (strain K12))
Explore P0AG44
Go to UniProtKB:  P0AG44
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L18 S117Escherichia coli K-12Mutation(s): 0
Gene Names: rplRb3304JW3266
Find proteins for P0C018 (Escherichia coli (strain K12))
Explore P0C018
Go to UniProtKB:  P0C018
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L19 T115Escherichia coli K-12Mutation(s): 0
Gene Names: rplSb2606JW2587
Find proteins for P0A7K6 (Escherichia coli (strain K12))
Explore P0A7K6
Go to UniProtKB:  P0A7K6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L20 U118Escherichia coli K-12Mutation(s): 0
Gene Names: rplTpdzAb1716JW1706
Find proteins for P0A7L3 (Escherichia coli (strain K12))
Explore P0A7L3
Go to UniProtKB:  P0A7L3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L21 V103Escherichia coli K-12Mutation(s): 0
Gene Names: rplUb3186JW3153
Find proteins for P0AG48 (Escherichia coli (strain K12))
Explore P0AG48
Go to UniProtKB:  P0AG48
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L22 W110Escherichia coli K-12Mutation(s): 0
Gene Names: rplVeryBb3315JW3277
Find proteins for P61175 (Escherichia coli (strain K12))
Explore P61175
Go to UniProtKB:  P61175
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L23 X100Escherichia coli K-12Mutation(s): 0
Gene Names: rplWb3318JW3280
Find proteins for P0ADZ0 (Escherichia coli (strain K12))
Explore P0ADZ0
Go to UniProtKB:  P0ADZ0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L24 Y104Escherichia coli K-12Mutation(s): 0
Gene Names: rplXb3309JW3271
Find proteins for P60624 (Escherichia coli (strain K12))
Explore P60624
Go to UniProtKB:  P60624
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L25 Z94Escherichia coli K-12Mutation(s): 0
Gene Names: rplYb2185JW2173
Find proteins for P68919 (Escherichia coli (strain K12))
Explore P68919
Go to UniProtKB:  P68919
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L27 085Escherichia coli K-12Mutation(s): 0
Gene Names: rpmAb3185JW3152
Find proteins for P0A7L8 (Escherichia coli (strain K12))
Explore P0A7L8
Go to UniProtKB:  P0A7L8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 23
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L28 178Escherichia coli K-12Mutation(s): 0
Gene Names: rpmBb3637JW3612
Find proteins for P0A7M2 (Escherichia coli (strain K12))
Explore P0A7M2
Go to UniProtKB:  P0A7M2
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 24
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L29 263Escherichia coli K-12Mutation(s): 0
Gene Names: rpmCb3312JW3274
Find proteins for P0A7M6 (Escherichia coli (strain K12))
Explore P0A7M6
Go to UniProtKB:  P0A7M6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 25
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L30 359Escherichia coli K-12Mutation(s): 0
Gene Names: rpmDb3302JW3264
Find proteins for P0AG51 (Escherichia coli (strain K12))
Explore P0AG51
Go to UniProtKB:  P0AG51
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 26
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L31 470Escherichia coli K-12Mutation(s): 0
Gene Names: rpmEb3936JW3907
Find proteins for P0A7M9 (Escherichia coli (strain K12))
Explore P0A7M9
Go to UniProtKB:  P0A7M9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 27
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L32 557Escherichia coli K-12Mutation(s): 0
Gene Names: rpmFb1089JW1075
Find proteins for P0A7N4 (Escherichia coli (strain K12))
Explore P0A7N4
Go to UniProtKB:  P0A7N4
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 28
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L33 655Escherichia coli K-12Mutation(s): 0
Gene Names: rpmGb3636JW3611
Find proteins for P0A7N9 (Escherichia coli (strain K12))
Explore P0A7N9
Go to UniProtKB:  P0A7N9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 29
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L34 746Escherichia coli K-12Mutation(s): 0
Gene Names: rpmHrimAssaFb3703JW3680
Find proteins for P0A7P5 (Escherichia coli (strain K12))
Explore P0A7P5
Go to UniProtKB:  P0A7P5
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 30
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L35 865Escherichia coli K-12Mutation(s): 0
Gene Names: rpmIb1717JW1707
Find proteins for P0A7Q1 (Escherichia coli (strain K12))
Explore P0A7Q1
Go to UniProtKB:  P0A7Q1
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 31
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L36 938Escherichia coli K-12Mutation(s): 0
Gene Names: rpmJb3299JW3261
Find proteins for P0A7Q6 (Escherichia coli (strain K12))
Explore P0A7Q6
Go to UniProtKB:  P0A7Q6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 33
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S2 b240Escherichia coli K-12Mutation(s): 0
Gene Names: rpsBb0169JW0164
Find proteins for P0A7V0 (Escherichia coli (strain K12))
Explore P0A7V0
Go to UniProtKB:  P0A7V0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 34
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S3 c233Escherichia coli K-12Mutation(s): 0
Gene Names: rpsCb3314JW3276
Find proteins for P0A7V3 (Escherichia coli (strain K12))
Explore P0A7V3
Go to UniProtKB:  P0A7V3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 35
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S4 d206Escherichia coli K-12Mutation(s): 0
Gene Names: rpsDramAb3296JW3258
Find proteins for P0A7V8 (Escherichia coli (strain K12))
Explore P0A7V8
Go to UniProtKB:  P0A7V8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 36
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S5 e167Escherichia coli K-12Mutation(s): 0
Gene Names: rpsEspcb3303JW3265
Find proteins for P0A7W1 (Escherichia coli (strain K12))
Explore P0A7W1
Go to UniProtKB:  P0A7W1
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 37
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S6 f135Escherichia coli K-12Mutation(s): 0
Gene Names: rpsFb4200JW4158
Find proteins for P02358 (Escherichia coli (strain K12))
Explore P02358
Go to UniProtKB:  P02358
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 38
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S7 g179Escherichia coli K-12Mutation(s): 0
Gene Names: rpsGb3341JW3303
Find proteins for P02359 (Escherichia coli (strain K12))
Explore P02359
Go to UniProtKB:  P02359
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 39
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S8 h130Escherichia coli K-12Mutation(s): 0
Gene Names: rpsHb3306JW3268
Find proteins for P0A7W7 (Escherichia coli (strain K12))
Explore P0A7W7
Go to UniProtKB:  P0A7W7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 40
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S9 i130Escherichia coli K-12Mutation(s): 0
Gene Names: rpsIb3230JW3199
Find proteins for P0A7X3 (Escherichia coli (strain K12))
Explore P0A7X3
Go to UniProtKB:  P0A7X3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 41
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S10 j103Escherichia coli K-12Mutation(s): 0
Gene Names: rpsJnusEb3321JW3283
Find proteins for P0A7R5 (Escherichia coli (strain K12))
Explore P0A7R5
Go to UniProtKB:  P0A7R5
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 42
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S11 k129Escherichia coli K-12Mutation(s): 0
Gene Names: rpsKb3297JW3259
Find proteins for P0A7R9 (Escherichia coli (strain K12))
Explore P0A7R9
Go to UniProtKB:  P0A7R9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 43
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S12 l124Escherichia coli K-12Mutation(s): 0
Gene Names: rpsLstrAb3342JW3304
Find proteins for P0A7S3 (Escherichia coli (strain K12))
Explore P0A7S3
Go to UniProtKB:  P0A7S3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 44
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S13 m118Escherichia coli K-12Mutation(s): 0
Gene Names: rpsMb3298JW3260
Find proteins for P0A7S9 (Escherichia coli (strain K12))
Explore P0A7S9
Go to UniProtKB:  P0A7S9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 45
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S15 o89Escherichia coli K-12Mutation(s): 0
Gene Names: rpsOsecCb3165JW3134
Find proteins for P0ADZ4 (Escherichia coli (strain K12))
Explore P0ADZ4
Go to UniProtKB:  P0ADZ4
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 46
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S16 p82Escherichia coli K-12Mutation(s): 0
Gene Names: rpsPb2609JW2590
Find proteins for P0A7T3 (Escherichia coli (strain K12))
Explore P0A7T3
Go to UniProtKB:  P0A7T3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 47
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S17 q84Escherichia coli K-12Mutation(s): 0
Gene Names: rpsQneaAb3311JW3273
Find proteins for P0AG63 (Escherichia coli (strain K12))
Explore P0AG63
Go to UniProtKB:  P0AG63
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 48
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S18 r75Escherichia coli K-12Mutation(s): 0
Gene Names: rpsRb4202JW4160
Find proteins for P0A7T7 (Escherichia coli (strain K12))
Explore P0A7T7
Go to UniProtKB:  P0A7T7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 49
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S20 t87Escherichia coli K-12Mutation(s): 0
Gene Names: rpsTb0023JW0022
Find proteins for P0A7U7 (Escherichia coli (strain K12))
Explore P0A7U7
Go to UniProtKB:  P0A7U7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 50
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S21 u71Escherichia coli K-12Mutation(s): 0
Gene Names: rpsUb3065JW3037
Find proteins for P68679 (Escherichia coli (strain K12))
Explore P68679
Go to UniProtKB:  P68679
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 53
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L10 J165Escherichia coli K-12Mutation(s): 0
Gene Names: rplJb3985JW3948
Find proteins for P0A7J3 (Escherichia coli (strain K12))
Explore P0A7J3
Go to UniProtKB:  P0A7J3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 54
MoleculeChainsSequence LengthOrganismDetailsImage
50S ribosomal protein L11 K142Escherichia coli K-12Mutation(s): 0
Gene Names: rplKrelCb3983JW3946
Find proteins for P0A7J7 (Escherichia coli (strain K12))
Explore P0A7J7
Go to UniProtKB:  P0A7J7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 55
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S14 n102Escherichia coli K-12Mutation(s): 0
Gene Names: rpsNb3307JW3269
Find proteins for P0AG59 (Escherichia coli (strain K12))
Explore P0AG59
Go to UniProtKB:  P0AG59
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 56
MoleculeChainsSequence LengthOrganismDetailsImage
30S ribosomal protein S19 s92Escherichia coli K-12Mutation(s): 0
Gene Names: rpsSb3316JW3278
Find proteins for P0A7U3 (Escherichia coli (strain K12))
Explore P0A7U3
Go to UniProtKB:  P0A7U3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 57
MoleculeChainsSequence LengthOrganismDetailsImage
GTP pyrophosphokinase,GTP pyrophosphokinase,GTP pyrophosphokinase z819Escherichia coliEscherichia coli O157:H7Mutation(s): 0
Gene Names: relAZ4099ECs3644
EC: 2.7.6.5
Find proteins for P0AG20 (Escherichia coli (strain K12))
Explore P0AG20
Go to UniProtKB:  P0AG20
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsLengthOrganismImage
23S ribosomal RNAA2903Escherichia coli K-12
Find similar nucleic acids by:
(by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsLengthOrganismImage
5S ribosomal RNAB120Escherichia coli K-12
Find similar nucleic acids by:
(by identity cutoff)  |  Structure
Entity ID: 32
MoleculeChainsLengthOrganismImage
16S ribosomal RNAa1539Escherichia coli K-12
  • Find similar nucleic acids by:  Sequence   |   Structure
  • Entity ID: 51
    MoleculeChainsLengthOrganismImage
    mRNAv6Escherichia coli
    Find similar nucleic acids by:
    (by identity cutoff)  |  Structure
    Entity ID: 52
    MoleculeChainsLengthOrganismImage
    P-site tRNAx77Escherichia coli K-12
    Find similar nucleic acids by:
    (by identity cutoff)  |  Structure
    Entity ID: 58
    MoleculeChainsLengthOrganismImage
    deacylated A/R-tRNAy73Escherichia coli K-12
    Experimental Data & Validation

    Experimental Data

    • Method: ELECTRON MICROSCOPY
    • Resolution: 3.70 Å
    • Aggregation State: PARTICLE
    • Reconstruction Method: SINGLE PARTICLE

    Structure Validation

    View Full Validation Report



    Entry History & Funding Information

    Deposition Data


    Funding OrganizationLocationGrant Number
    German Research FoundationGermanyGRK1721
    German Research FoundationGermanyFOR-1805
    SPPGermany1879
    SFBGermany464
    Swedish Research CouncilSweden2013-4680

    Revision History  (Full details and data files)

    • Version 1.0: 2016-07-20
      Type: Initial release
    • Version 1.1: 2017-08-30
      Changes: Author supporting evidence, Data collection, Derived calculations, Experimental preparation
    • Version 1.2: 2017-09-13
      Changes: Author supporting evidence
    • Version 2.0: 2019-02-20
      Changes: Data collection, Derived calculations, Polymer sequence
    • Version 2.1: 2019-10-02
      Changes: Data collection, Other
