5L0L | pdb_00005l0l

Crystal structure of Uncharacterized protein LPG0439

• PDB DOI: https://doi.org/10.2210/pdb5L0L/pdb

• Classification: UNKNOWN FUNCTION
• Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
• Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
• Mutation(s): No


• Deposited: 2016-07-27 Released: 2016-08-10
• Deposition Author(s): Chang, C., Skarina, T., Khutoreskaya, G., Savchenko, A., Joachimiak, A.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.189 (Depositor), 0.188 (DCC)
• R-Value Work:
  0.169 (Depositor), 0.169 (DCC)
• R-Value Observed:
  0.170 (Depositor)

Literature

Crystal structure of Uncharacterized protein LPG0439

Chang, C., Skarina, T., Khutoreskaya, G., Savchenko, A., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 49.62 kDa
• Atom Count: 3,887
• Modeled Residue Count: 430
• Deposited Residue Count: 430
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A, B	215	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0  Gene Names: lpg0439
UniProt
Find proteins for Q5ZYD3 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZYD3  Go to UniProtKB:  Q5ZYD3

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
CL	E [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.189 (Depositor), 0.188 (DCC)
• R-Value Work:  0.169 (Depositor), 0.169 (DCC)
• R-Value Observed: 0.170 (Depositor)

Space Group: P 6₂ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 129.688	α = 90
b = 129.688	β = 90
c = 117.143	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
SCALEPACK	data scaling
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2016-08-10
Deposition Author(s): Chang, C., Skarina, T., Khutoreskaya, G., Savchenko, A., Joachimiak, A.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM115586

Revision History

• Version 1.0: 2016-08-10
  Type: Initial release

• Version 1.1: 2016-08-17
  Changes: Database references, Structure summary
• Version 1.2: 2017-09-20
  Changes: Author supporting evidence, Derived calculations
• Version 1.3: 2019-12-25
  Changes: Author supporting evidence
• Version 1.4: 2024-11-06
  Changes: Data collection, Database references, Structure summary
