5K5K | pdb_00005k5k

Crystal structure of laccasse from Thermus thermophilus HB27 (ascorbic acid 10 min)

PDB DOI: https://doi.org/10.2210/pdb5K5K/pdb

Classification: OXIDOREDUCTASE
Organism(s): Thermus thermophilus HB27
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2016-05-23 Released: 2017-06-07
Deposition Author(s): Diaz-Vilchis, A., Ruiz-Arellano, R.R., Rosas-Benitez, E., Rudino-Pinera, E.
Funding Organization(s): UNAM

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.216 (Depositor), 0.216 (DCC)
R-Value Work:
0.175 (Depositor), 0.175 (DCC)
R-Value Observed:
0.177 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5K5K

This is version 1.1 of the entry. See complete history.

Literature

Preserving metallic sites affected by radiation damage: the CuT2 case in Thermus thermophilus multicopper oxidase

Diaz-Vilchis, A., Ruiz-Arellano, R.R., Rosas-Benitez, E., Stojanoff, V., Rudino-Pinera, E.

To be published.

Macromolecule Content

Total Structure Weight: 50.4 kDa
Atom Count: 4,485
Modeled Residue Count: 439
Deposited Residue Count: 439
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Laccase	A	439	Thermus thermophilus HB27	Mutation(s): 0 Gene Names: TT_C1370 EC: 1.10.3.2
UniProt
Find proteins for Q72HW2 (Thermus thermophilus (strain ATCC BAA-163 / DSM 7039 / HB27)) Explore Q72HW2 Go to UniProtKB: Q72HW2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q72HW2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MPD Query on MPD Download:Ideal Coordinates CCD File SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth A] E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A]	(4S)-2-METHYL-2,4-PENTANEDIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-YFKPBYRVSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.216 (Depositor), 0.216 (DCC)
R-Value Work: 0.175 (Depositor), 0.175 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 93.44	α = 90
b = 109.86	β = 90
c = 96.05	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-06-07

Deposition Author(s):

Diaz-Vilchis, A.

Ruiz-Arellano, R.R.

Rosas-Benitez, E.

Rudino-Pinera, E.

Funding Organization	Location	Grant Number
UNAM	Mexico	DGAPA IN 209114-3

Revision History (Full details and data files)

Version 1.0: 2017-06-07
Type: Initial release
Version 1.1: 2023-09-27
Changes: Data collection, Database references, Refinement description
