5JHQ

ARCs 1-3 of human Tankyrase-1 bound to a peptide derived from IRAP

  • Classification: TRANSFERASE
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2016-04-21 Released: 2016-09-21
  • Deposition Author(s): Eisemann, T., Pascal, J.M.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.214
  • R-Value Observed: 0.215

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Tankyrase-1 Ankyrin Repeats Form an Adaptable Binding Platform for Targets of ADP-Ribose Modification.

Eisemann, T.McCauley, M.Langelier, M.F.Gupta, K.Roy, S.Van Duyne, G.D.Pascal, J.M.

(2016) Structure 24: 1679-1692

  • DOI: https://doi.org/10.1016/j.str.2016.07.014
  • Primary Citation of Related Structures:
    5JHQ

  • PubMed Abstract:

    The poly(ADP-ribose) polymerase enzyme Tankyrase-1 (TNKS) regulates multiple cellular processes and interacts with diverse proteins using five ankyrin repeat clusters (ARCs). There are limited structural insights into functional roles of the multiple ARCs of TNKS. Here we present the ARC1-3 crystal structure and employ small-angle X-ray scattering (SAXS) to investigate solution conformations of the complete ankyrin repeat domain. Mutagenesis and binding studies using the bivalent TNKS binding domain of Axin1 demonstrate that only certain ARC combinations function together. The physical basis for these restrictions is explained by both rigid and flexible ankyrin repeat elements determined in our structural analysis. SAXS analysis is consistent with a dynamic ensemble of TNKS ankyrin repeat conformations modulated by Axin1 interaction. TNKS ankyrin repeat domain is thus an adaptable binding platform with structural features that can explain selectivity toward diverse proteins, and has implications for TNKS positioning of bound targets for poly(ADP-ribose) modification.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Sidney Kimmel Cancer Center, Thomas Jefferson University, Philadelphia, PA 19107, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tankyrase-1
A, B, C, D
482Homo sapiensMutation(s): 0
Gene Names: TNKSPARP5APARPLTIN1TINF1TNKS1
EC: 2.4.2.30
UniProt & NIH Common Fund Data Resources
Find proteins for O95271 (Homo sapiens)
Explore O95271
Go to UniProtKB:  O95271
PHAROS:  O95271
GTEx:  ENSG00000173273
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO95271
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Peptide derived from insulin-responsive aminopeptidase (IRAP)
E, F, G, H, I
E, F, G, H, I, J, K, L
16Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UIQ6 (Homo sapiens)
Explore Q9UIQ6
Go to UniProtKB:  Q9UIQ6
PHAROS:  Q9UIQ6
GTEx:  ENSG00000113441
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UIQ6
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.214
  • R-Value Observed: 0.215
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.51α = 90
b = 129.83β = 92.31
c = 123.95γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM087282

Revision History  (Full details and data files)

  • Version 1.0: 2016-09-21
    Type: Initial release
  • Version 1.1: 2016-10-19
    Changes: Database references
  • Version 1.2: 2017-09-27
    Changes: Author supporting evidence, Database references, Derived calculations
  • Version 1.3: 2019-12-25
    Changes: Author supporting evidence
  • Version 1.4: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
