5J9Q | pdb_00005j9q

Crystal structure of the NuA4 core complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.25 Å
  • R-Value Free:
    0.273 (Depositor), 0.275 (DCC)
  • R-Value Work:
    0.250 (Depositor), 0.253 (DCC)
  • R-Value Observed:
    0.251 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5J9Q

This is version 1.2 of the entry. See complete history

Literature

The NuA4 Core Complex Acetylates Nucleosomal Histone H4 through a Double Recognition Mechanism

Xu, P.Li, C.Chen, Z.Jiang, S.Fan, S.Wang, J.Dai, J.Zhu, P.Chen, Z.

(2016) Mol Cell 63: 965-975

  • DOI: https://doi.org/10.1016/j.molcel.2016.07.024
  • Primary Citation Related Structures:
    5J9Q, 5J9T, 5J9U, 5J9W

  • PubMed Abstract:

    NuA4 catalyzes the acetylation of nucleosomes at histone H4, which is a well-established epigenetic event, controlling many genomic processes in Saccharomyces cerevisiae. Here we report the crystal structures of the NuA4 core complex and a cryoelectron microscopy structure with the nucleosome. The structures show that the histone-binding pocket of the enzyme is rearranged, suggesting its activation. The enzyme binds the histone tail mainly through the target lysine residue, with a preference for a small residue at the -1 position. The complex engages the nucleosome at the dish face and orients its catalytic pocket close to the H4 tail to achieve selective acetylation. The combined data reveal a space-sequence double recognition mechanism of the histone tails by a modifying enzyme in the context of the nucleosome.


  • Organizational Affiliation
    • MOE Key Laboratory of Protein Science, Tsinghua University, Beijing 100086, China; School of Life Science, Tsinghua University, Beijing 100086, China.

Macromolecule Content

  • Total Structure Weight: 318.35 kDa
  • Atom Count: 19,671
  • Modeled Residue Count: 2,356
  • Deposited Residue Count: 2,697
  • Unique protein chains: 5

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Histone acetyltransferase ESA1A [auth E],
D [auth A],
E [auth I]
305Saccharomyces cerevisiae S288CMutation(s): 1
Gene Names: ESA1YOR244WO5257
EC: 2.3.1.48 (PDB Primary Data), 2.3.1 (UniProt)
UniProt
Find proteins for Q08649 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q08649
Go to UniProtKB:  Q08649
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08649
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Chromatin modification-related protein EAF6B [auth F],
I [auth B],
J
113Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: EAF6YJR082CJ1854
UniProt
Find proteins for P47128 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47128
Go to UniProtKB:  P47128
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47128
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Enhancer of polycomb-like protein 1C [auth G],
F [auth N],
G [auth C]
351Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: EPL1YFL024C
UniProt
Find proteins for P43572 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P43572
Go to UniProtKB:  P43572
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP43572
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Chromatin modification-related protein YNG2H [auth D],
K [auth H],
L [auth K]
120Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: YNG2EAF4NBN1YHR090C
UniProt
Find proteins for P38806 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38806
Go to UniProtKB:  P38806
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38806
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Htz1M [auth L],
N [auth M],
O
10Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for Q12692 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12692
Go to UniProtKB:  Q12692
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12692
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
ALY
Query on ALY
A [auth E],
D [auth A],
E [auth I]
L-PEPTIDE LINKINGC8 H16 N2 O3LYS

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.25 Å
  • R-Value Free:  0.273 (Depositor), 0.275 (DCC)
  • R-Value Work:  0.250 (Depositor), 0.253 (DCC)
  • R-Value Observed: 0.251 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 217.857α = 90
b = 190.99β = 113.56
c = 172.346γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
autoSHARPphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (China)China2014CB910100

Revision History  (Full details and data files)

  • Version 1.0: 2016-10-26
    Type: Initial release
  • Version 1.1: 2017-10-18
    Changes: Author supporting evidence, Database references, Derived calculations
  • Version 1.2: 2024-10-30
    Changes: Data collection, Database references, Structure summary
