5J92 | pdb_00005j92

Crystal structure of a putative alpha-ketoglutarate dependent 2,4-D dioxygenase from Burkholderia xenovorans

• PDB DOI: https://doi.org/10.2210/pdb5J92/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Paraburkholderia xenovorans LB400
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2016-04-08 Released: 2016-05-11
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free:
  0.215 (Depositor), 0.210 (DCC)
• R-Value Work:
  0.176 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.178 (Depositor)

Starting Model: experimental

Literature

Crystal structure of a putative alpha-ketoglutarate dependent 2,4-D dioxygenase from Burkholderia xenovorans

Conrady, D.G., Dranow, D.M., Lorimer, D., Edwards, T.E.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 141.34 kDa
• Atom Count: 9,414
• Modeled Residue Count: 1,032
• Deposited Residue Count: 1,236
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative alpha KG dependent 2,4-D dioxygenase	A, B, C, D	309	Paraburkholderia xenovorans LB400	Mutation(s): 0  Gene Names: Bxe_B2152 EC: 1.14.11
UniProt
Find proteins for Q13Q05 (Paraburkholderia xenovorans (strain LB400)) Explore Q13Q05  Go to UniProtKB:  Q13Q05

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ACT	H [auth C]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M
FE2	E [auth A], F [auth B], G [auth C], I [auth D]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free:  0.215 (Depositor), 0.210 (DCC)
• R-Value Work:  0.176 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.178 (Depositor)

Diffraction Data: https://doi.org/10.18430/M35J92

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.7	α = 90
b = 77.88	β = 92.11
c = 92.14	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
MOLREP	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2016-05-11
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2016-05-11
  Type: Initial release

• Version 1.1: 2023-09-27
  Changes: Data collection, Database references, Derived calculations, Refinement description
