5IW1 | pdb_00005iw1

Crystal Structure of B4.2.3 T-Cell Receptor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.268 (Depositor), 0.279 (DCC)
  • R-Value Work:
    0.240 (Depositor), 0.239 (DCC)
  • R-Value Observed:
    0.243 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5IW1

This is version 1.3 of the entry. See complete history

Literature

An allosteric site in the T-cell receptor C beta domain plays a critical signalling role.

Natarajan, K.McShan, A.C.Jiang, J.Kumirov, V.K.Wang, R.Zhao, H.Schuck, P.Tilahun, M.E.Boyd, L.F.Ying, J.Bax, A.Margulies, D.H.Sgourakis, N.G.

(2017) Nat Commun 8: 15260-15260

  • DOI: https://doi.org/10.1038/ncomms15260
  • Primary Citation Related Structures:
    5IVX, 5IW1

  • PubMed Abstract:

    The molecular mechanism through which the interaction of a clonotypic αβ T-cell receptor (TCR) with a peptide-loaded major histocompatibility complex (p/MHC) leads to T-cell activation is not yet fully understood. Here we exploit a high-affinity TCR (B4.2.3) to examine the structural changes that accompany binding to its p/MHC ligand (P18-I10/H2-D d ). In addition to conformational changes in complementarity-determining regions (CDRs) of the TCR seen in comparison of unliganded and bound X-ray structures, NMR characterization of the TCR β-chain dynamics reveals significant chemical shift effects in sites removed from the MHC-binding site. Remodelling of electrostatic interactions near the Cβ H3 helix at the membrane-proximal face of the TCR, a region implicated in interactions with the CD3 co-receptor, suggests a possible role for an allosteric mechanism in TCR signalling. The contribution of these TCR residues to signal transduction is supported by mutagenesis and T-cell functional assays.


  • Organizational Affiliation
    • Molecular Biology Section, Laboratory of Immunology, National Institute of Allergy and Infectious Diseases, National Institutes of Health, Bethesda, Maryland 20892, USA.

Macromolecule Content

  • Total Structure Weight: 145.7 kDa
  • Atom Count: 10,062
  • Modeled Residue Count: 1,266
  • Deposited Residue Count: 1,287
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
T-CELL RECEPTOR ALPHA CHAIN
A, C, E
194Mus musculusMutation(s): 0
Gene Names: TCRAV2S6J38
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
T-CELL RECEPTOR BETA CHAIN
B, D, F
235Mus musculusMutation(s): 0
Gene Names: TCRAV2S6J38

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.268 (Depositor), 0.279 (DCC)
  • R-Value Work:  0.240 (Depositor), 0.239 (DCC)
  • R-Value Observed: 0.243 (Depositor)
Space Group: P 31
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 96.112α = 90
b = 96.112β = 90
c = 167.578γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-03-29
    Type: Initial release
  • Version 1.1: 2017-06-21
    Changes: Database references
  • Version 1.2: 2023-09-27
    Changes: Advisory, Data collection, Database references, Refinement description
  • Version 1.3: 2024-10-23
    Changes: Structure summary
