5ITZ

Crystal structure of the SAC domain of CPAP in a complex with Tubulin and Darpin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.177

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Centriolar CPAP/SAS-4 Imparts Slow Processive Microtubule Growth.

Sharma, A.Aher, A.Dynes, N.J.Frey, D.Katrukha, E.A.Jaussi, R.Grigoriev, I.Croisier, M.Kammerer, R.A.Akhmanova, A.Gonczy, P.Steinmetz, M.O.

(2016) Dev.Cell 37: 362-376

  • DOI: 10.1016/j.devcel.2016.04.024

  • PubMed Abstract:
  • Centrioles are fundamental and evolutionarily conserved microtubule-based organelles whose assembly is characterized by microtubule growth rates that are orders of magnitude slower than those of cytoplasmic microtubules. Several centriolar proteins c ...

    Centrioles are fundamental and evolutionarily conserved microtubule-based organelles whose assembly is characterized by microtubule growth rates that are orders of magnitude slower than those of cytoplasmic microtubules. Several centriolar proteins can interact with tubulin or microtubules, but how they ensure the exceptionally slow growth of centriolar microtubules has remained mysterious. Here, we bring together crystallographic, biophysical, and reconstitution assays to demonstrate that the human centriolar protein CPAP (SAS-4 in worms and flies) binds and "caps" microtubule plus ends by associating with a site of β-tubulin engaged in longitudinal tubulin-tubulin interactions. Strikingly, we uncover that CPAP activity dampens microtubule growth and stabilizes microtubules by inhibiting catastrophes and promoting rescues. We further establish that the capping function of CPAP is important to limit growth of centriolar microtubules in cells. Our results suggest that CPAP acts as a molecular lid that ensures slow assembly of centriolar microtubules and, thereby, contributes to organelle length control.


    Organizational Affiliation

    Laboratory of Biomolecular Research, Department of Biology and Chemistry, Paul Scherrer Institut, 5232 Villigen PSI, Switzerland.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Tubulin alpha-1B chain
A
451Bos taurusMutation(s): 0
Find proteins for P81947 (Bos taurus)
Go to UniProtKB:  P81947
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Tubulin beta-2B chain
B
445Bos taurusMutation(s): 0
Gene Names: TUBB2B
Find proteins for Q6B856 (Bos taurus)
Go to Gene View: TUBB2B
Go to UniProtKB:  Q6B856
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Centromere protein J
D
129Homo sapiensMutation(s): 0
Gene Names: CENPJ (CPAP, LAP, LIP1)
Find proteins for Q9HC77 (Homo sapiens)
Go to Gene View: CENPJ
Go to UniProtKB:  Q9HC77
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
Designed ankyrin repeat protein (DARPIN) D1
F
127N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GDP
Query on GDP

Download SDF File
Download CCD File
B
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
 Ligand Interaction
GTP
Query on GTP

Download SDF File
Download CCD File
A
GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O14 P3
XKMLYUALXHKNFT-UUOKFMHZSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
LOC
Query on LOC

Download SDF File
Download CCD File
B
N-[(7S)-1,2,3,10-tetramethoxy-9-oxo-6,7-dihydro-5H-benzo[d]heptalen-7-yl]ethanamide
COLCHICINE
C22 H25 N O6
IAKHMKGGTNLKSZ-INIZCTEOSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.2 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.177
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 61.080α = 90.00
b = 85.340β = 91.77
c = 98.690γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland310030B_138659

Revision History

  • Version 1.0: 2016-06-01
    Type: Initial release
