5ISM | pdb_00005ism

Human DPP4 in complex with a novel 5,5,6-tricyclic pyrrolidine inhibitor

PDB DOI: https://doi.org/10.2210/pdb5ISM/pdb

Classification: Hydrolase/Hydrolase Inhibitor
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): Yes

Deposited: 2016-03-15 Released: 2016-05-11
Deposition Author(s): Scapin, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.201 (Depositor), 0.200 (DCC)
R-Value Work:
0.165 (Depositor)
R-Value Observed:
0.167 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.1 of the entry. See complete history.

Literature

The discovery of novel 5,6,5- and 5,5,6-tricyclic pyrrolidines as potent and selective DPP-4 inhibitors.

Cox, J.M., Chu, H.D., Kuethe, J.T., Gao, Y.D., Scapin, G., Eiermann, G., He, H., Li, X., Lyons, K.A., Metzger, J., Petrov, A., Wu, J.K., Xu, S., Sinha-Roy, R., Weber, A.E., Biftu, T.

(2016) Bioorg Med Chem Lett 26: 2622-2626

PubMed: 27106708 Search on PubMed
DOI: https://doi.org/10.1016/j.bmcl.2016.04.020
Primary Citation Related Structures:
5ISM

PubMed Abstract:
Novel potent and selective 5,6,5- and 5,5,6-tricyclic pyrrolidine dipeptidyl peptidase IV (DPP-4) inhibitors were identified. Structure-activity relationship (SAR) efforts focused on improving the intrinsic DPP-4 inhibition potency, increasing protease selectivity, and demonstrating clean ion channel and cytochrome P450 profiles while trying to achieve a pharmacokinetic profile suitable for once weekly dosing in humans.

Organizational Affiliation

Department of Chemistry, Merck Research Laboratories, 2015 Galloping Hill Road, Kenilworth, NJ 07033, USA. Electronic address: jason_cox@merck.com.

Macromolecule Content

Total Structure Weight: 173.57 kDa
Atom Count: 14,017
Modeled Residue Count: 1,456
Deposited Residue Count: 1,456
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Dipeptidyl peptidase 4	A, B	728	Homo sapiens	Mutation(s): 1 Gene Names: DPP4, ADCP2, CD26 EC: 3.4.14.5
UniProt & NIH Common Fund Data Resources
Find proteins for P27487 (Homo sapiens) Explore P27487 Go to UniProtKB: P27487
PHAROS: P27487 GTEx: ENSG00000197635
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P27487
Glycosylation
Glycosylation Sites: 5	Glycosylation Focus chain A Focus chain B	Go to GlyGen: P27487-1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, D, E, F, G C, D, E, F, G, H, I	2		N-Glycosylation	Interactions Focus chain C Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Focus chain I Interactions & Density Focus chain C Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Focus chain I
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
6DG Query on 6DG Download:Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain P [auth B] MOL2 format, chain N [auth A] MOL2 format, chain P [auth B] mmCIF format, chain N [auth A] mmCIF format, chain P [auth B]	N [auth A], P [auth B]	(2R,3S,5R)-2-(2,5-difluorophenyl)-5-(7H-pyrrolo[3',4':3,4]pyrazolo[1,5-a]pyrimidin-8(9H)-yl)oxan-3-amine C₁₉ H₁₉ F₂ N₅ O CEOQJSZJQDMDFU-PZPSRYQVSA-N		Interactions Focus chain N [auth A] Focus chain P [auth B] Interactions & Density Focus chain N [auth A] Focus chain P [auth B]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain O [auth B] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain O [auth B] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain O [auth B]	J [auth A], K [auth A], L [auth A], O [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain O [auth B] Interactions & Density Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain O [auth B]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain M [auth A] MOL2 format, chain M [auth A] mmCIF format, chain M [auth A]	M [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain M [auth A] Interactions & Density Focus chain M [auth A]

Binding Affinity Annotations
ID	Source	Binding Affinity
6DG	BindingDB: 5ISM	IC50: 0.7 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.201 (Depositor), 0.200 (DCC)
R-Value Work: 0.165 (Depositor)
R-Value Observed: 0.167 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 118.274	α = 90
b = 126.029	β = 90
c = 137.273	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data collection
SCALEPACK	data scaling
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-05-11

Deposition Author(s):

Scapin, G.

Revision History (Full details and data files)

Version 1.0: 2016-05-11
Type: Initial release
Version 1.1: 2016-05-18
Changes: Database references
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Structure summary
Version 2.1: 2024-10-30
Changes: Data collection, Database references, Structure summary
