5IG4

Crystal structure of N. vectensis CaMKII-A hub


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.35 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.192

wwPDB Validation 3D Report Full Report


This is version 1.4 of the entry. See complete history

Literature

Molecular mechanism of activation-triggered subunit exchange in Ca(2+)/calmodulin-dependent protein kinase II.

Bhattacharyya, M.Stratton, M.M.Going, C.C.McSpadden, E.D.Huang, Y.Susa, A.C.Elleman, A.Cao, Y.M.Pappireddi, N.Burkhardt, P.Gee, C.L.Barros, T.Schulman, H.Williams, E.R.Kuriyan, J.

(2016) Elife 5: --

  • DOI: 10.7554/eLife.13405
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Activation triggers the exchange of subunits in Ca(2+)/calmodulin-dependent protein kinase II (CaMKII), an oligomeric enzyme that is critical for learning, memory, and cardiac function. The mechanism by which subunit exchange occurs remains elusive. ...

    Activation triggers the exchange of subunits in Ca(2+)/calmodulin-dependent protein kinase II (CaMKII), an oligomeric enzyme that is critical for learning, memory, and cardiac function. The mechanism by which subunit exchange occurs remains elusive. We show that the human CaMKII holoenzyme exists in dodecameric and tetradecameric forms, and that the calmodulin (CaM)-binding element of CaMKII can bind to the hub of the holoenzyme and destabilize it to release dimers. The structures of CaMKII from two distantly diverged organisms suggest that the CaM-binding element of activated CaMKII acts as a wedge by docking at intersubunit interfaces in the hub. This converts the hub into a spiral form that can release or gain CaMKII dimers. Our data reveal a three-way competition for the CaM-binding element, whereby phosphorylation biases it towards the hub interface, away from the kinase domain and calmodulin, thus unlocking the ability of activated CaMKII holoenzymes to exchange dimers with unactivated ones.


    Organizational Affiliation

    California Institute for Quantitative Biosciences, University of California, Berkeley, Berkeley, United States.,Biophysics Graduate Group, University of California, Berkeley, Berkeley, United States.,Department of Chemistry, University of California, Berkeley, Berkeley, United States.,Physical Biosciences Division, Lawrence Berkeley National Laboratory, Berkeley, United States.,Allosteros Therapeutics, Sunnyvale, United States.,Howard Hughes Medical Institute, University of California, Berkeley, Berkeley, United States.,Department of Molecular and Cell Biology, University of California, Berkeley, Berkeley, United States.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Predicted protein
A, B, C, D, E, F, G
145Nematostella vectensisMutation(s): 0
Find proteins for A7T0H5 (Nematostella vectensis)
Go to UniProtKB:  A7T0H5
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
B, C
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.35 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.192
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 78.466α = 90.00
b = 180.100β = 90.00
c = 179.511γ = 90.00
Software Package:
Software NamePurpose
PHASERphasing
XDSdata reduction
Aimlessdata scaling
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Howard Hughes Medical InstituteUnited StatesNA

Revision History

  • Version 1.0: 2016-03-23
    Type: Initial release
  • Version 1.1: 2016-04-06
    Type: Structure summary
  • Version 1.2: 2016-04-20
    Type: Structure summary
  • Version 1.3: 2016-07-13
    Type: Data collection
  • Version 1.4: 2017-09-27
    Type: Author supporting evidence, Derived calculations
