5HVW

Monomeric IgG4 Fc


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.258
  • R-Value Work: 0.209

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Generation and Characterization of an IgG4 Monomeric Fc Platform.

Shan, L.Colazet, M.Rosenthal, K.L.Yu, X.Q.Bee, J.S.Ferguson, A.Damschroder, M.M.Wu, H.Dall'Acqua, W.F.Tsui, P.Oganesyan, V.

(2016) Plos One 11: e0160345-e0160345

  • DOI: 10.1371/journal.pone.0160345

  • PubMed Abstract:
  • The immunoglobulin Fc region is a homodimer consisted of two sets of CH2 and CH3 domains and has been exploited to generate two-arm protein fusions with high expression yields, simplified purification processes and extended serum half-life. However, ...

    The immunoglobulin Fc region is a homodimer consisted of two sets of CH2 and CH3 domains and has been exploited to generate two-arm protein fusions with high expression yields, simplified purification processes and extended serum half-life. However, attempts to generate one-arm fusion proteins with monomeric Fc, with one set of CH2 and CH3 domains, are often plagued with challenges such as weakened binding to FcRn or partial monomer formation. Here, we demonstrate the generation of a stable IgG4 Fc monomer with a unique combination of mutations at the CH3-CH3 interface using rational design combined with in vitro evolution methodologies. In addition to size-exclusion chromatography and analytical ultracentrifugation, we used multi-angle light scattering (MALS) to show that the engineered Fc monomer exhibits excellent monodispersity. Furthermore, crystal structure analysis (PDB ID: 5HVW) reveals monomeric properties supported by disrupted interactions at the CH3-CH3 interface. Monomeric Fc fusions with Fab or scFv achieved FcRn binding and serum half-life comparable to wildtype IgG. These results demonstrate that this monomeric IgG4 Fc is a promising therapeutic platform to extend the serum half-life of proteins in a monovalent format.


    Organizational Affiliation

    Discovery Sciences, Structure and Biophysics, AstraZeneca Pharmaceuticals, Waltham, Massachusetts, United States of America.,Antibody Discovery and Protein Engineering, MedImmune, Gaithersburg, Maryland, United States of America.,Clinical Pharmacology and Drug Metabolism and Pharmacokinetics, MedImmune, Gaithersburg, Maryland, United States of America.,Analytical Biotechnology, MedImmune, Gaithersburg, Maryland, United States of America.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Ig gamma-4 chain C region
A
210N/AMutation(s): 5
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 7 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
MAN
Query on MAN

Download SDF File
Download CCD File
A
ALPHA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
 Ligand Interaction
FUC
Query on FUC

Download SDF File
Download CCD File
A
ALPHA-L-FUCOSE
C6 H12 O5
SHZGCJCMOBCMKK-SXUWKVJYSA-N
 Ligand Interaction
GAL
Query on GAL

Download SDF File
Download CCD File
A
BETA-D-GALACTOSE
C6 H12 O6
WQZGKKKJIJFFOK-FPRJBGLDSA-N
 Ligand Interaction
BMA
Query on BMA

Download SDF File
Download CCD File
A
BETA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-RWOPYEJCSA-N
 Ligand Interaction
NAG
Query on NAG

Download SDF File
Download CCD File
A
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.258
  • R-Value Work: 0.209
  • Space Group: H 3 2
Unit Cell:
Length (Å)Angle (°)
a = 121.379α = 90.00
b = 121.379β = 90.00
c = 99.729γ = 120.00
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
MOLREPphasing
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2016-08-17
    Type: Initial release
