5HUS | pdb_00005hus

Structure of Candida albicans trehalose synthase regulatory protein C-terminal domain

PDB DOI: https://doi.org/10.2210/pdb5HUS/pdb

Classification: TRANSFERASE
Organism(s): Candida albicans SC5314
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2016-01-27 Released: 2017-05-03
Deposition Author(s): Miao, Y., Brennan, R.G.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.217 (Depositor), 0.222 (DCC)
R-Value Work:
0.186 (Depositor), 0.192 (DCC)
R-Value Observed:
0.188 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5HUS

This is version 1.3 of the entry. See complete history.

Literature

Structure of Candida albicans trehalose synthase regulatory protein C-terminal domain

Miao, Y., Brennan, R.G.

To be published.

Macromolecule Content

Total Structure Weight: 33.91 kDa
Atom Count: 2,528
Modeled Residue Count: 293
Deposited Residue Count: 306
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
trehalose synthase regulatory protein	A	306	Candida albicans SC5314	Mutation(s): 0 Gene Names: TPS3, CaO19.12808, CaO19.5348
UniProt
Find proteins for A0A1D8PIS4 (Candida albicans (strain SC5314 / ATCC MYA-2876)) Explore A0A1D8PIS4 Go to UniProtKB: A0A1D8PIS4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A1D8PIS4
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.217 (Depositor), 0.222 (DCC)
R-Value Work: 0.186 (Depositor), 0.192 (DCC)
R-Value Observed: 0.188 (Depositor)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 106.94	α = 90
b = 106.94	β = 90
c = 41.886	γ = 120

Software Package:

Software Name	Purpose
HKL-2000	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2017-05-03

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	1P01AI104533-01A1

Revision History (Full details and data files)

Version 1.0: 2017-05-03
Type: Initial release
Version 1.1: 2017-09-20
Changes: Author supporting evidence
Version 1.2: 2019-12-11
Changes: Author supporting evidence
Version 1.3: 2024-03-06
Changes: Data collection, Database references
