5H29 | pdb_00005h29

Crystal Structure of the NTD_N/C domain of Alkylhydroperoxide Reductase AhpF from Enterococcus Faecalis (V583)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.229 (Depositor), 0.225 (DCC)
  • R-Value Work:
    0.194 (Depositor), 0.198 (DCC)
  • R-Value Observed:
    0.196 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5H29

This is version 1.2 of the entry. See complete history

Literature

Novel insights into the vancomycin-resistant Enterococcus faecalis (V583) alkylhydroperoxide reductase subunit F

Toh, Y.K.Balakrishna, A.M.Manimekalai, M.S.S.Chionh, B.B.Seetharaman, R.R.C.Eisenhaber, F.Eisenhaber, B.Gruber, G.

(2017) Biochim Biophys Acta 1861: 3201-3214

  • DOI: https://doi.org/10.1016/j.bbagen.2017.09.011
  • Primary Citation Related Structures:
    5H29

  • PubMed Abstract:

    The ability of the vancomycin-resistant Enterococcus faecalis (V583) to restore redox homeostasis via antioxidant defense mechanism is of importance, and knowledge into this defense is essential to understand its antibiotic-resistance and survival in hosts. The flavoprotein disulfide reductase AhpR, composed of the subunits AhpC and AhpF, represents one such vital part. Circular permutation was found to be a feature of the AhpF protein family. E. faecalis (V583) AhpF (EfAhpF) appears to be a representative of a minor subclass of this family, the typically N-terminal two-fold thioredoxin-like domain (NTD_N/C) is located at the C-terminus, whereas the pyridine nucleotide-disulfide oxidoreductase domain is encoded in the N-terminal part of its sequence. In EfAhpF, these two domains are connected via an unusually long linker region providing optimal communication between both domains. EfAhpF forms a dimer in solution similar to Escherichia coli AhpF. The crystallographic 2.3Å resolution structure of the NTD_N/C domain reveals a unique loop-helix stretch ( 409 ILKDTEPAKELLYGIEKM 426 ) not present in homologue domains of other prokaryotic AhpFs. Deletion of the unique 415 PAKELLY 421 -helix or of 415 PAKELL 420 affects protein stability or attenuates peroxidase activity. Furthermore, mutation of Y421 is described to be essential for E. faecalis AhpF's optimal NADH-oxidative activity.


  • Organizational Affiliation
    • Bioinformatics Institute, Agency for Science, Technology and Research (A*STAR), 30 Biopolis Street, #07-01 Matrix, Singapore 138671, Republic of Singapore.

Macromolecule Content

  • Total Structure Weight: 24.62 kDa
  • Atom Count: 1,740
  • Modeled Residue Count: 207
  • Deposited Residue Count: 218
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Thioredoxin reductase/glutathione-related protein218Enterococcus faecalis V583Mutation(s): 0
Gene Names: EF_2738
UniProt
Find proteins for Q830N9 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q830N9
Go to UniProtKB:  Q830N9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ830N9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.229 (Depositor), 0.225 (DCC)
  • R-Value Work:  0.194 (Depositor), 0.198 (DCC)
  • R-Value Observed: 0.196 (Depositor)
Space Group: P 41 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 134.278α = 90
b = 134.278β = 90
c = 134.278γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-11-22
    Type: Initial release
  • Version 1.1: 2023-11-08
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2024-11-06
    Changes: Structure summary
