5GX3

Luciferin-regenerating enzyme collected with serial synchrotron rotational crystallography with accumulated dose of 6.9 MGy (6th measurement)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.182
  • R-Value Work: 0.167

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Development of a dose-limiting data collection strategy for serial synchrotron rotation crystallography

Hasegawa, K.Yamashita, K.Murai, T.Nuemket, N.Hirata, K.Ueno, G.Ago, H.Nakatsu, T.Kumasaka, T.Yamamoto, M.

(2017) J Synchrotron Radiat 24: 29-41

  • DOI: 10.1107/S1600577516016362
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Serial crystallography, in which single-shot diffraction images are collected, has great potential for protein microcrystallography. Although serial femtosecond crystallography (SFX) has been successfully demonstrated, limited beam time prevents its ...

    Serial crystallography, in which single-shot diffraction images are collected, has great potential for protein microcrystallography. Although serial femtosecond crystallography (SFX) has been successfully demonstrated, limited beam time prevents its routine use. Inspired by SFX, serial synchrotron crystallography (SSX) has been investigated at synchrotron macromolecular crystallography beamlines. Unlike SFX, the longer exposure time of milliseconds to seconds commonly used in SSX causes radiation damage. However, in SSX, crystals can be rotated during the exposure, which can achieve efficient coverage of the reciprocal space. In this study, mercury single-wavelength anomalous diffraction (Hg-SAD) phasing of the luciferin regenerating enzyme (LRE) was performed using serial synchrotron rotation crystallography. The advantages of rotation and influence of dose on the data collected were evaluated. The results showed that sample rotation was effective for accurate data collection, and the optimum helical rotation step depended on multiple factors such as multiplicity and partiality of reflections, exposure time per rotation angle and the contribution from background scattering. For the LRE microcrystals, 0.25° was the best rotation step for the achievable resolution limit, whereas a rotation step larger than or equal to 1° was favorable for Hg-SAD phasing. Although an accumulated dose beyond 1.1 MGy caused specific damage at the Hg site, increases in resolution and anomalous signal were observed up to 3.4 MGy because of a higher signal-to-noise ratio.


    Organizational Affiliation

    Japan Synchrotron Radiation Research Institute, 1-1-1 Kouto, Sayo 679-5198, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Luciferin regenerating enzyme
A
311Photinus pyralisMutation(s): 0
Find proteins for Q95YI4 (Photinus pyralis)
Go to UniProtKB:  Q95YI4
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
MPD
Query on MPD

Download SDF File
Download CCD File
A
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
 Ligand Interaction
HG
Query on HG

Download SDF File
Download CCD File
A
MERCURY (II) ION
Hg
BQPIGGFYSBELGY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.182
  • R-Value Work: 0.167
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 47.469α = 90.00
b = 76.859β = 90.00
c = 84.326γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata processing
PHENIXphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-01-04
    Type: Initial release
