5GEP

SULFITE REDUCTASE HEMOPROTEIN CARBON MONOXIDE COMPLEX REDUCED WITH CRII EDTA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Work: 0.184

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Probing the catalytic mechanism of sulfite reductase by X-ray crystallography: structures of the Escherichia coli hemoprotein in complex with substrates, inhibitors, intermediates, and products.

Crane, B.R.Siegel, L.M.Getzoff, E.D.

(1997) Biochemistry 36: 12120-12137

  • DOI: 10.1021/bi971066i
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • To further understand the six-electron reductions of sulfite and nitrite catalyzed by the Escherichia coli sulfite reductase hemoprotein (SiRHP), we have determined crystallographic structures of the enzyme in complex with the inhibitors phosphate, c ...

    To further understand the six-electron reductions of sulfite and nitrite catalyzed by the Escherichia coli sulfite reductase hemoprotein (SiRHP), we have determined crystallographic structures of the enzyme in complex with the inhibitors phosphate, carbon monoxide, and cyanide, the substrates sulfite and nitrite, the intermediate nitric oxide, the product sulfide (or, most likely, an oxidized derivative thereof), and an oxidized nitrogen species (probably nitrate). A hydrogen-bonded cage of ligand-binding arginine and lysine side chains, ordered water molecules, and siroheme carboxylates provides preferred locations for recognizing the common functional groups of these ligands and accommodates their varied sizes, shapes, and charged without requiring substantial structural changes. The coordination geometries presented here suggest that the successively deoxygenated sulfur and nitrogen species produced during catalysis need not alter their orientation in the active site to adopt new stable coordination states. Strong pi-acid ligands decrease the bond length between the siroheme and the proximal cysteine thiolate shared with the iron-sulfur cluster, emphasizing the ability of the coupled cofactors to promote electron tranfer into substrate. On binding the siroheme, the substrate sulfite provides an oxygen atom in a unique location of the binding site compared to all other ligands studied, induces a spin transition in the siroheme iron, flips an active-site arginine, and orders surrounding active-center loops. The loop that coalesces over the active center shields the positively charged ligand-coordinating residues from solvent, enhancing their ability to polarize the substrate. Hydrogen bonds supplied by active-site arginine and lysine residues facilitate charge transfer into the substrate from the electron-rich cofactors, activate S-O bonds for reductive cleavage, and provide potential proton sources for the formation of favorable aquo leaving groups on the substrate. Strong interactions between sulfite and ordered water molecules also implicate solvent as a source of protons for generating product water. From the structures reported here, we propose a series of key structural states of ligated SiRHP in the catalytic reduction of sulfite to sulfide.


    Related Citations:
    • Sulfite Reductase Structure at 1.6 A: Evolution and Catalysis for Reduction of Inorganic Anions
      Crane, B.R.,Siegel, L.M.,Getzoff, E.D.
      (1995) Science 270: 59


    Organizational Affiliation

    Department of Molecular Biology, The Scripps Research Institute, La Jolla, California 92037, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
SULFITE REDUCTASE HEMOPROTEIN
A
497Escherichia coli (strain K12)Mutation(s): 0
Gene Names: cysI
EC: 1.8.1.2
Find proteins for P17846 (Escherichia coli (strain K12))
Go to UniProtKB:  P17846
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
K
Query on K

Download SDF File
Download CCD File
A
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
 Ligand Interaction
SF4
Query on SF4

Download SDF File
Download CCD File
A
IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-VKOJMFJBAC
 Ligand Interaction
SRM
Query on SRM

Download SDF File
Download CCD File
A
SIROHEME
C42 H42 Fe N4 O16
PGYXHNRRBJLFEV-NBUGCWMUSA-N
 Ligand Interaction
CMO
Query on CMO

Download SDF File
Download CCD File
A
CARBON MONOXIDE
C O
UGFAIRIUMAVXCW-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Work: 0.184
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 69.800α = 90.00
b = 77.400β = 90.00
c = 87.800γ = 90.00
Software Package:
Software NamePurpose
X-PLORrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1998-01-14
    Type: Initial release
  • Version 1.1: 2008-03-25
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Source and taxonomy, Version format compliance
  • Version 1.3: 2017-11-29
    Type: Derived calculations, Other
