5FZ9 | pdb_00005fz9

Crystal structure of the catalytic domain of human JARID1B in complex with Maybridge fragment thieno(3,2-b)thiophene-5-carboxylic acid (N06263b) (ligand modelled based on PANDDA event map, SGC - Diamond I04-1 fragment screening)

PDB DOI: https://doi.org/10.2210/pdb5FZ9/pdb

Classification: OXIDOREDUCTASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2016-03-12 Released: 2016-03-30
Deposition Author(s): Nowak, R., Krojer, T., Johansson, C., Kupinska, K., Szykowska, A., Pearce, N., Talon, R., Collins, P., Gileadi, C., Strain-Damerell, C., Burgess-Brown, N.A., Arrowsmith, C.H., Bountra, C., Edwards, A.M., von Delft, F., Brennan, P.E., Oppermann, U.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.06 Å
R-Value Free:
0.228 (Depositor), 0.203 (DCC)
R-Value Work:
0.195 (Depositor)
R-Value Observed:
0.197 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of the Catalytic Domain of Human Jarid1B in Complex with Maybridge Fragment Thieno(3,2-B)Thiophene -5-Carboxylic Acid (N06263B) (Ligand Modelled Based on Pandda Event Map, Sgc - Diamond I04-1 Fragment Screening)

Nowak, R., Krojer, T., Johansson, C., Kupinska, K., Szykowska, A., Pearce, N., Talon, R., Collins, P., Gileadi, C., Strain-Damerell, C., Burgess-Brown, N.A., Arrowsmith, C.H., Bountra, C., Edwards, A.M., von Delft, F., Brennan, P.E., Oppermann, U.

To be published.

Macromolecule Content

Total Structure Weight: 56.87 kDa
Atom Count: 4,181
Modeled Residue Count: 454
Deposited Residue Count: 479
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
LYSINE-SPECIFIC DEMETHYLASE 5B	A	479	Homo sapiens	Mutation(s): 0 EC: 1.14.11 (PDB Primary Data), 1.14.11.67 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UGL1 (Homo sapiens) Explore Q9UGL1 Go to UniProtKB: Q9UGL1
PHAROS: Q9UGL1 GTEx: ENSG00000117139
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9UGL1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 8 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EPE Query on EPE Download:Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
NUK Query on NUK Download:Ideal Coordinates CCD File SDF format, chain Q [auth A] SDF format, chain P [auth A] SDF format, chain O [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A]	O [auth A], P [auth A], Q [auth A]	thieno[3,2-b]thiophene-5-carboxylic acid C₇ H₄ O₂ S₂ GVZXSZWCZGKLRS-UHFFFAOYSA-N		Interactions Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Interactions & Density Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain R [auth A] MOL2 format, chain R [auth A] mmCIF format, chain R [auth A]	R [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain R [auth A] Interactions & Density Focus chain R [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], F [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	I [auth A], J [auth A], K [auth A], L [auth A], M [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A]
MN Query on MN Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.06 Å
R-Value Free: 0.228 (Depositor), 0.203 (DCC)
R-Value Work: 0.195 (Depositor)
R-Value Observed: 0.197 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 143.51	α = 90
b = 143.51	β = 90
c = 154.05	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
SCALA	data scaling
DIMPLE	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-03-30

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2016-03-30
Type: Initial release
Version 1.1: 2018-01-24
Changes: Database references, Structure summary
Version 1.2: 2024-01-10
Changes: Data collection, Database references, Derived calculations, Other, Refinement description
