5FYW

Transcription initiation complex structures elucidate DNA opening (OC)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.35 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 2.0 of the entry. See complete history

Literature

Transcription Initiation Complex Structures Elucidate DNA Opening

Plaschka, C.Hantsche, M.Dienemann, C.Burzinski, C.Plitzko, J.Cramer, P.

(2016) Nature 533: 353

  • DOI: 10.1038/nature17990
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Transcription of eukaryotic protein-coding genes begins with assembly of the RNA polymerase (Pol) II initiation complex and promoter DNA opening. Here we report cryo-electron microscopy (cryo-EM) structures of yeast initiation complexes containing cl ...

    Transcription of eukaryotic protein-coding genes begins with assembly of the RNA polymerase (Pol) II initiation complex and promoter DNA opening. Here we report cryo-electron microscopy (cryo-EM) structures of yeast initiation complexes containing closed and open DNA at resolutions of 8.8 Å and 3.6 Å, respectively. DNA is positioned and retained over the Pol II cleft by a network of interactions between the TATA-box-binding protein TBP and transcription factors TFIIA, TFIIB, TFIIE, and TFIIF. DNA opening occurs around the tip of the Pol II clamp and the TFIIE 'extended winged helix' domain, and can occur in the absence of TFIIH. Loading of the DNA template strand into the active centre may be facilitated by movements of obstructing protein elements triggered by allosteric binding of the TFIIE 'E-ribbon' domain. The results suggest a unified model for transcription initiation with a key event, the trapping of open promoter DNA by extended protein-protein and protein-DNA contacts.


    Organizational Affiliation

    Max Planck Institute for Biochemistry, Am Klopferspitz 18, 82152 Martinsried, Germany.,Max Planck Institute for Biophysical Chemistry, Department of Molecular Biology, Am Fassberg 11, 37077 Göttingen, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB1
A
1733Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPO21 (RPB1, RPB220, SUA8)
EC: 2.7.7.6
Find proteins for P04050 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04050
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB2
B
1224Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB2 (RPB150, RPO22)
EC: 2.7.7.6
Find proteins for P08518 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P08518
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB3
C
318Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB3
Find proteins for P16370 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P16370
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB4
D
221Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB4
Find proteins for P20433 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20433
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 1
E
215Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB5 (RPA7, RPC9)
Find proteins for P20434 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20434
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 2
F
155Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPO26 (RPB6)
Find proteins for P20435 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20435
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB7
G
171Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB7
Find proteins for P34087 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P34087
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 3
H
146Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB8
Find proteins for P20436 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20436
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB9
I
122Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB9
Find proteins for P27999 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P27999
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 5
J
70Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB10
Find proteins for P22139 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P22139
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB11
K
120Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPB11
Find proteins for P38902 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38902
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 4
L
70Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPC10 (RPB12)
Find proteins for P40422 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40422
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIB
M
345Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: SUA7
Find proteins for P29055 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P29055
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
TATA-BOX-BINDING PROTEIN
O
240Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: SPT15 (BTF1, TBP1)
Find proteins for P13393 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P13393
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIF SUBUNIT ALPHA
Q
735Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TFG1 (SSU71)
Find proteins for P41895 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P41895
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIF SUBUNIT BETA
R
400Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TFG2
Find proteins for P41896 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P41896
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIA LARGE SUBUNIT
U
286Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TOA1
Find proteins for P32773 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P32773
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIA SUBUNIT 2
V
122Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TOA2
Find proteins for P32774 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P32774
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIE SUBUNIT ALPHA
W
482Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TFA1
Find proteins for P36100 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P36100
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIE SUBUNIT BETA
X
328Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TFA2
Find proteins for P36145 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P36145
Entity ID: 14
MoleculeChainsLengthOrganism
NONTEMPLATE DNAN72synthetic construct
Entity ID: 18
MoleculeChainsLengthOrganism
NONTEMPLATE DNAT72synthetic construct
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, C, I, J, L, M, W
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.35 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2016-05-18
    Type: Initial release
  • Version 1.1: 2016-05-25
    Type: Database references
  • Version 1.2: 2016-06-01
    Type: Database references
  • Version 1.3: 2017-04-19
    Type: Other
  • Version 2.0: 2018-10-03
    Type: Advisory, Atomic model, Data collection, Derived calculations
