Structure of the Pds5-Scc1 complex and implications for cohesin function

Experimental Data Snapshot

  • Resolution: 5.80 Å
  • R-Value Free: 0.311
  • R-Value Work: 0.249
  • R-Value Observed: 0.249

wwPDB Validation   3D Report Full Report

This is version 1.6 of the entry. See complete history


Structure of the Pds5-Scc1 Complex and Implications for Cohesin Function

Muir, K.W.Kschonsak, M.Li, Y.Metz, J.Haering, C.H.Panne, D.

(2016) Cell Rep 14: 2116

  • DOI: https://doi.org/10.1016/j.celrep.2016.01.078
  • Primary Citation of Related Structures:
    5FRP, 5FRR, 5FRS

  • PubMed Abstract:

    Sister chromatid cohesion is a fundamental prerequisite to faithful genome segregation. Cohesion is precisely regulated by accessory factors that modulate the stability with which the cohesin complex embraces chromosomes. One of these factors, Pds5, engages cohesin through Scc1 and is both a facilitator of cohesion, and, conversely also mediates the release of cohesin from chromatin. We present here the crystal structure of a complex between budding yeast Pds5 and Scc1, thus elucidating the molecular basis of Pds5 function. Pds5 forms an elongated HEAT repeat that binds to Scc1 via a conserved surface patch. We demonstrate that the integrity of the Pds5-Scc1 interface is indispensable for the recruitment of Pds5 to cohesin, and that its abrogation results in loss of sister chromatid cohesion and cell viability.

  • Organizational Affiliation

    European Molecular Biology Laboratory Grenoble Outstation and Unit of Virus Host-Cell Interactions, University Grenoble Alpes-CNRS-EMBL, 71 Avenue des Martyrs, CS 90181, 38042 Grenoble Cedex 9, France.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B
703Saccharomyces cerevisiaeMutation(s): 0
Find proteins for Q04264 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q04264
Go to UniProtKB:  Q04264
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ04264
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 5.80 Å
  • R-Value Free: 0.311
  • R-Value Work: 0.249
  • R-Value Observed: 0.249
  • Space Group: I 4 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 283.69α = 90
b = 283.69β = 90
c = 172.79γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-03-02
    Type: Initial release
  • Version 1.1: 2016-03-09
    Changes: Database references
  • Version 1.2: 2016-03-23
    Changes: Database references
  • Version 1.3: 2016-04-27
    Changes: Data collection
  • Version 1.4: 2017-08-23
    Changes: Data collection
  • Version 1.5: 2023-05-03
    Changes: Data collection, Database references, Other
  • Version 1.6: 2024-06-19
    Changes: Data collection
