5F3J

Crystal structure of DBP in complex with inhibitory monoclonal antibody 2D10


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.00 Å
  • R-Value Free: 0.300
  • R-Value Work: 0.267
  • R-Value Observed: 0.269

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Broadly neutralizing epitopes in the Plasmodium vivax vaccine candidate Duffy Binding Protein.

Chen, E.Salinas, N.D.Huang, Y.Ntumngia, F.Plasencia, M.D.Gross, M.L.Adams, J.H.Tolia, N.H.

(2016) Proc Natl Acad Sci U S A 113: 6277-6282

  • DOI: https://doi.org/10.1073/pnas.1600488113
  • Primary Citation of Related Structures:
    5F3J

  • PubMed Abstract:

    Plasmodium vivax Duffy Binding Protein (PvDBP) is the most promising vaccine candidate for P. vivax malaria. The polymorphic nature of PvDBP induces strain-specific immune responses, however, and the epitopes of broadly neutralizing antibodies are unknown. These features hamper the rational design of potent DBP-based vaccines and necessitate the identification of globally conserved epitopes. Using X-ray crystallography, small-angle X-ray scattering, hydrogen-deuterium exchange mass spectrometry, and mutational mapping, we have defined epitopes for three inhibitory mAbs (mAbs 2D10, 2H2, and 2C6) and one noninhibitory mAb (3D10) that engage DBP. These studies expand the currently known inhibitory epitope repertoire by establishing protective motifs in subdomain three outside the receptor-binding and dimerization residues of DBP, and introduce globally conserved protective targets. All of the epitopes are highly conserved among DBP alleles. The identification of broadly conserved epitopes of inhibitory antibodies provides critical motifs that should be retained in the next generation of potent vaccines for P. vivax malaria.


  • Organizational Affiliation

    Department of Molecular Microbiology, Washington University School of Medicine in St. Louis, St. Louis, MO 63110;


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Duffy receptor
A, B
317Plasmodium vivax Sal-1Mutation(s): 0
Gene Names: PVDR
UniProt
Find proteins for P22290 (Plasmodium vivax (strain Salvador I))
Explore P22290
Go to UniProtKB:  P22290
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22290
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Antibody 2D10 single chain variable fragment
C, D
305Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.00 Å
  • R-Value Free: 0.300
  • R-Value Work: 0.267
  • R-Value Observed: 0.269
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 84.94α = 90
b = 63.94β = 100.09
c = 108.88γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI080792
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR56 AI080792
Burroughs Wellcome FundUnited StatesPATH award
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI064478
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesBAA-NIAID-DAIT-NIHAI2013164

Revision History  (Full details and data files)

  • Version 1.0: 2016-05-18
    Type: Initial release
  • Version 1.1: 2016-06-01
    Changes: Database references
  • Version 1.2: 2016-06-15
    Changes: Database references
  • Version 1.3: 2017-09-13
    Changes: Author supporting evidence, Database references, Derived calculations
  • Version 1.4: 2019-12-11
    Changes: Author supporting evidence
  • Version 1.5: 2023-09-27
    Changes: Data collection, Database references, Refinement description
