5F3A | pdb_00005f3a

Crystal structure of the bromodomain of human ATAD2 in complex with Compound A14

• PDB DOI: https://doi.org/10.2210/pdb5F3A/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2015-12-02 Released: 2016-12-14
• Deposition Author(s): Dong, J., Caflisch, A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free:
  0.210 (Depositor), 0.180 (DCC)
• R-Value Work:
  0.179 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.181 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the bromodomain of human ATAD2 in complex with Compound A14

Dong, J., Caflisch, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 15.78 kDa
• Atom Count: 1,187
• Modeled Residue Count: 130
• Deposited Residue Count: 130
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ATPase family AAA domain-containing protein 2	A	130	Homo sapiens	Mutation(s): 0  Gene Names: ATAD2, L16, PRO2000 EC: 3.6.1.3 (PDB Primary Data), 3.6.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q6PL18 (Homo sapiens) Explore Q6PL18  Go to UniProtKB:  Q6PL18
PHAROS:  Q6PL18 GTEx:  ENSG00000156802

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
5U9	C [auth A]	~{N}-(4-ethanoyl-1,3-thiazol-2-yl)azetidin-1-ium-3-carboxamide C9 H12 N3 O2 S HHOKILYJEJQQMO-UHFFFAOYSA-O
SO4	B [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free:  0.210 (Depositor), 0.180 (DCC)
• R-Value Work:  0.179 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.181 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.938	α = 90
b = 79.938	β = 90
c = 137.533	γ = 120

Software Package:

Software Name	Purpose
SCALA	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2016-12-14
Deposition Author(s): Dong, J., Caflisch, A.

Revision History

• Version 1.0: 2016-12-14
  Type: Initial release

• Version 1.1: 2024-01-10
  Changes: Data collection, Database references, Refinement description
