5DW8 | pdb_00005dw8

Crystal structure of 2'AMP bound SaIMPase-II

PDB DOI: https://doi.org/10.2210/pdb5DW8/pdb

Classification: HYDROLASE
Organism(s): Staphylococcus aureus
Expression System: Escherichia coli M15
Mutation(s): No

Deposited: 2015-09-22 Released: 2015-12-09
Deposition Author(s): Dutta, A., Bhattacharyya, S., Das, A.K.
Funding Organization(s): Department of Biotechnology

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.266 (Depositor), 0.269 (DCC)
R-Value Work:
0.205 (Depositor), 0.210 (DCC)
R-Value Observed:
0.209 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5DW8

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of 2'AMP bound SaIMPase-II

Dutta, A., Bhattacharyya, S., Das, A.K.

To be published.

Macromolecule Content

Total Structure Weight: 63.87 kDa
Atom Count: 4,192
Modeled Residue Count: 519
Deposited Residue Count: 566
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Inositol monophosphatase	A, B	283	Staphylococcus aureus	Mutation(s): 0 Gene Names: sas1042 EC: 3.1.3.25

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
2AM Query on 2AM Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain I [auth B] MOL2 format, chain D [auth A] MOL2 format, chain I [auth B] mmCIF format, chain D [auth A] mmCIF format, chain I [auth B]	D [auth A], I [auth B]	ADENOSINE-2'-MONOPHOSPHATE C₁₀ H₁₄ N₅ O₇ P QDFHPFSBQFLLSW-KQYNXXCUSA-N		Interactions Focus chain D [auth A] Focus chain I [auth B] Interactions & Density Focus chain D [auth A] Focus chain I [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain E [auth A] SDF format, chain G [auth B] SDF format, chain H [auth B] MOL2 format, chain C [auth A] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] MOL2 format, chain H [auth B] mmCIF format, chain C [auth A] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B] mmCIF format, chain H [auth B]	C [auth A], E [auth A], G [auth B], H [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain E [auth A] Focus chain G [auth B] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain E [auth A] Focus chain G [auth B] Focus chain H [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.266 (Depositor), 0.269 (DCC)
R-Value Work: 0.205 (Depositor), 0.210 (DCC)
R-Value Observed: 0.209 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.008	α = 90
b = 105.687	β = 101.91
c = 53.313	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2015-12-09

Deposition Author(s):

Bhattacharyya, S.

Funding Organization	Location	Grant Number
Department of Biotechnology	India	--

Revision History (Full details and data files)

Version 1.0: 2015-12-09
Type: Initial release
Version 1.1: 2024-03-20
Changes: Data collection, Database references, Derived calculations
