5DIL | pdb_00005dil

Crystal structure of the effector domain of the NS1 protein from influenza virus B

• PDB DOI: https://doi.org/10.2210/pdb5DIL/pdb

• Classification: RNA-binding Protein, Viral Protein
• Organism(s): Influenza B virus (B/Singapore/DSO_090134/2004)
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2015-09-01 Released: 2016-08-10
• Deposition Author(s): Guan, R., Hamilton, K., Ma, L., Montelione, G.T.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.01 Å
• R-Value Free:
  0.242 (Depositor), 0.242 (DCC)
• R-Value Work:
  0.194 (Depositor), 0.194 (DCC)
• R-Value Observed:
  0.199 (Depositor)

Literature

A Second RNA-Binding Site in the NS1 Protein of Influenza B Virus.

Ma, L.C., Guan, R., Hamilton, K., Aramini, J.M., Mao, L., Wang, S., Krug, R.M., Montelione, G.T.

(2016) Structure 24: 1562-1572

• PubMed: 27545620
• DOI: https://doi.org/10.1016/j.str.2016.07.001
• Primary Citation Related Structures:
  5DIL


• PubMed Abstract:


  Influenza viruses cause a highly contagious respiratory disease in humans. The NS1 proteins of influenza A and B viruses (NS1A and NS1B proteins, respectively) are composed of two domains, a dimeric N-terminal domain and a C-terminal domain, connected by a flexible polypeptide linker. Here we report the 2.0-Å X-ray crystal structure and nuclear magnetic resonance studies of the NS1B C-terminal domain, which reveal a novel and unexpected basic RNA-binding site that is not present in the NS1A protein. We demonstrate that single-site alanine replacements of basic residues in this site lead to reduced RNA-binding activity, and that recombinant influenza B viruses expressing these mutant NS1B proteins are severely attenuated in replication. This novel RNA-binding site of NS1B is required for optimal influenza B virus replication. Most importantly, this study reveals an unexpected RNA-binding function in the C-terminal domain of NS1B, a novel function that distinguishes influenza B viruses from influenza A viruses.

---

Organizational Affiliation:
• Department of Molecular Biology and Biochemistry, Center for Advanced Biotechnology and Medicine, Rutgers, The State University of New Jersey, Northeast Structural Genomics Consortium, Piscataway, NJ 08854, USA.
Department of Molecular Biosciences, Center for Infectious Disease, Institute for Cellular and Molecular Biology, University of Texas at Austin, Austin, TX 78712, USA.
Department of Molecular Biosciences, Center for Infectious Disease, Institute for Cellular and Molecular Biology, University of Texas at Austin, Austin, TX 78712, USA. Electronic address: [e-mail].
Department of Molecular Biology and Biochemistry, Center for Advanced Biotechnology and Medicine, Rutgers, The State University of New Jersey, Northeast Structural Genomics Consortium, Piscataway, NJ 08854, USA; Department of Biochemistry and Molecular Biology, Robert Wood Johnson Medical School, Rutgers, The State University of New Jersey, Piscataway, NJ 08854, USA. Electronic address: [e-mail].

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 33.67 kDa
• Atom Count: 2,398
• Modeled Residue Count: 273
• Deposited Residue Count: 282
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 1	A, B	141	Influenza B virus (B/Singapore/DSO_090134/2004)	Mutation(s): 0  Gene Names: NS1
UniProt
Find proteins for X2C382 (Influenza B virus) Explore X2C382  Go to UniProtKB:  X2C382

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IOD	C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth B], L [auth B], M [auth B], N [auth B], O [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.01 Å
• R-Value Free:  0.242 (Depositor), 0.242 (DCC)
• R-Value Work:  0.194 (Depositor), 0.194 (DCC)
• R-Value Observed: 0.199 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.689	α = 68.72
b = 41.666	β = 82.83
c = 49.681	γ = 78.12

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2016-08-10
Deposition Author(s): Guan, R., Hamilton, K., Ma, L., Montelione, G.T.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	--

Revision History

• Version 1.0: 2016-08-10
  Type: Initial release

• Version 1.1: 2016-10-05
  Changes: Database references
• Version 1.2: 2017-09-27
  Changes: Author supporting evidence, Database references, Derived calculations
• Version 1.3: 2019-12-25
  Changes: Author supporting evidence
• Version 1.4: 2024-11-20
  Changes: Data collection, Database references, Structure summary
