5CZR | pdb_00005czr

Crystal Structure of Human Protocadherin-24 EC1-2

PDB DOI: https://doi.org/10.2210/pdb5CZR/pdb

Classification: CELL ADHESION
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2015-08-01 Released: 2016-11-02
Deposition Author(s): Johnson, Z.R., Sotomayor, M.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.235 (Depositor), 0.241 (DCC)
R-Value Work:
0.205 (Depositor), 0.209 (DCC)
R-Value Observed:
0.206 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of Human Protocadherin-24 EC1-2

Johnson, Z.R., Sotomayor, M.

To be published.

Macromolecule Content

Total Structure Weight: 99.67 kDa
Atom Count: 6,864
Modeled Residue Count: 863
Deposited Residue Count: 900
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cadherin-related family member 2	A, B, C, D	225	Homo sapiens	Mutation(s): 0 Gene Names: CDHR2, PCDH24, PCLKC
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BYE9 (Homo sapiens) Explore Q9BYE9 Go to UniProtKB: Q9BYE9
PHAROS: Q9BYE9 GTEx: ENSG00000074276
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9BYE9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain Q [auth D] SDF format, chain S [auth D] SDF format, chain T [auth D] SDF format, chain R [auth D] SDF format, chain P [auth C] SDF format, chain O [auth C] SDF format, chain N [auth C] SDF format, chain M [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain Q [auth D] MOL2 format, chain S [auth D] MOL2 format, chain T [auth D] MOL2 format, chain R [auth D] MOL2 format, chain P [auth C] MOL2 format, chain O [auth C] MOL2 format, chain N [auth C] MOL2 format, chain M [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain Q [auth D] mmCIF format, chain S [auth D] mmCIF format, chain T [auth D] mmCIF format, chain R [auth D] mmCIF format, chain P [auth C] mmCIF format, chain O [auth C] mmCIF format, chain N [auth C] mmCIF format, chain M [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth B] E [auth A], F [auth A], G [auth A], H [auth A], I [auth B], J [auth B], K [auth B], L [auth B], M [auth C], N [auth C], O [auth C], P [auth C], Q [auth D], R [auth D], S [auth D], T [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth C] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth D] Focus chain R [auth D] Focus chain S [auth D] Focus chain T [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth C] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth D] Focus chain R [auth D] Focus chain S [auth D] Focus chain T [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.235 (Depositor), 0.241 (DCC)
R-Value Work: 0.205 (Depositor), 0.209 (DCC)
R-Value Observed: 0.206 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.879	α = 90
b = 119.769	β = 104.12
c = 74.318	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-11-02

Deposition Author(s):

Johnson, Z.R.

Sotomayor, M.

Revision History (Full details and data files)

Version 1.0: 2016-11-02
Type: Initial release
Version 1.1: 2023-09-27
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.2: 2024-11-13
Changes: Structure summary
