5CUK

Crystal structure of the PscP SS domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.191

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

The Structure of a Type 3 Secretion System (T3SS) Ruler Protein Suggests a Molecular Mechanism for Needle Length Sensing.

Bergeron, J.R.Fernandez, L.Wasney, G.A.Vuckovic, M.Reffuveille, F.Hancock, R.E.Strynadka, N.C.

(2016) J.Biol.Chem. 291: 1676-1691

  • DOI: 10.1074/jbc.M115.684423
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The type 3 secretion system (T3SS) and the bacterial flagellum are related pathogenicity-associated appendages found at the surface of many disease-causing bacteria. These appendages consist of long tubular structures that protrude away from the bact ...

    The type 3 secretion system (T3SS) and the bacterial flagellum are related pathogenicity-associated appendages found at the surface of many disease-causing bacteria. These appendages consist of long tubular structures that protrude away from the bacterial surface to interact with the host cell and/or promote motility. A proposed "ruler" protein tightly regulates the length of both the T3SS and the flagellum, but the molecular basis for this length control has remained poorly characterized and controversial. Using the Pseudomonas aeruginosa T3SS as a model system, we report the first structure of a T3SS ruler protein, revealing a "ball-and-chain" architecture, with a globular C-terminal domain (the ball) preceded by a long intrinsically disordered N-terminal polypeptide chain. The dimensions and stability of the globular domain do not support its potential passage through the inner lumen of the T3SS needle. We further demonstrate that a conserved motif at the N terminus of the ruler protein interacts with the T3SS autoprotease in the cytosolic side. Collectively, these data suggest a potential mechanism for needle length sensing by ruler proteins, whereby upon T3SS needle assembly, the ruler protein's N-terminal end is anchored on the cytosolic side, with the globular domain located on the extracellular end of the growing needle. Sequence analysis of T3SS and flagellar ruler proteins shows that this mechanism is probably conserved across systems.


    Organizational Affiliation

    From the Department of Biochemistry and Molecular Biology, the Centre for Blood Research, and.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Ruler protein
A
120Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)Mutation(s): 0
Gene Names: pscP
Find proteins for Q9I332 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Go to UniProtKB:  Q9I332
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.191
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 103.140α = 90.00
b = 42.480β = 99.07
c = 25.860γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
SCALAdata scaling
PHASERphasing
MOSFLMdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-12-02
    Type: Initial release
  • Version 1.1: 2016-02-03
    Type: Database references
