5C4Y | pdb_00005c4y

Crystal structure of putative TetR family transcription factor from Listeria monocytogenes

• PDB DOI: https://doi.org/10.2210/pdb5C4Y/pdb

• Classification: TRANSCRIPTION
• Organism(s): Listeria monocytogenes EGD-e
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2015-06-18 Released: 2015-07-08
• Deposition Author(s): Chang, C., Tesar, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.77 Å
• R-Value Free:
  0.206 (Depositor), 0.214 (DCC)
• R-Value Work:
  0.162 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.164 (Depositor)

Literature

Crystal structure of putative TetR family transcription factor from Listeria monocytogenes

Chang, C., Tesar, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 42.86 kDa
• Atom Count: 2,590
• Modeled Residue Count: 272
• Deposited Residue Count: 368
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative transcription regulator Lmo0852	A, B	184	Listeria monocytogenes EGD-e	Mutation(s): 0  Gene Names: lmo0852
UniProt
Find proteins for Q8Y8P4 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e)) Explore Q8Y8P4  Go to UniProtKB:  Q8Y8P4

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
EDO	C [auth A], D [auth B]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Modified Residue	Modification Type	Formula	2D Diagram
MSE	A, B	MET	Selenomethionine	C5 H11 N O2 Se

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.77 Å
• R-Value Free:  0.206 (Depositor), 0.214 (DCC)
• R-Value Work:  0.162 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.164 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 195.697	α = 90
b = 52.169	β = 104.97
c = 50.403	γ = 90

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	phasing
SBC-Collect	data collection
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2015-07-08
Deposition Author(s): Chang, C., Tesar, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2015-07-08
  Type: Initial release

• Version 1.1: 2024-10-23
  Changes: Data collection, Database references, Derived calculations, Source and taxonomy, Structure summary
