5C22

Crystal structure of Zn-bound HlyD from E. coli


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.302 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.227

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal Structure of a Soluble Fragment of the Membrane Fusion Protein HlyD in a Type I Secretion System of Gram-Negative Bacteria

Kim, J.S.Song, S.Lee, M.Lee, S.Lee, K.Ha, N.C.

(2016) Structure 24: 477-485

  • DOI: 10.1016/j.str.2015.12.012
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The protein toxin HlyA of Escherichia coli is exported without a periplasmic intermediate by the type I secretion system (T1SS). The T1SS is composed of an inner membrane ABC transporter HlyB, an outer-membrane channel protein TolC, and a membrane fu ...

    The protein toxin HlyA of Escherichia coli is exported without a periplasmic intermediate by the type I secretion system (T1SS). The T1SS is composed of an inner membrane ABC transporter HlyB, an outer-membrane channel protein TolC, and a membrane fusion protein HlyD. However, the assembly of the T1SS remains to be elucidated. In this study, we determine the crystal structure of a part of the C-terminal periplasmic domain of HlyD. The long α-helical domain consisting of three α helices and a lipoyl domain was identified in the crystal structure. Based on the HlyD structure, we modeled the hexameric assembly of HlyD with a long α-helical barrel, which formed a complex with TolC in an intermeshing cogwheel-to-cogwheel manner, as observed in tripartite RND-type drug efflux pumps. These observations provide a structural blueprint for understanding the type I secretion system in pathogenic Gram-negative bacteria.


    Organizational Affiliation

    Department of Agricultural Biotechnology, Center for Food Safety and Toxicology, Center for Food and Bioconvergence, Research Institute for Agricultural and Life Sciences, Seoul National University, Room #200-1041, 1 Gwanak-ro, Gwanak-gu, Seoul 151-921, Republic of Korea.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Chromosomal hemolysin D
A, B, C, D
279Escherichia coliMutation(s): 0
Gene Names: hlyD
Find proteins for P09986 (Escherichia coli)
Go to UniProtKB:  P09986
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, D
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.302 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.227
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 80.865α = 90.00
b = 94.476β = 90.00
c = 181.378γ = 90.00
Software Package:
Software NamePurpose
iMOSFLMdata reduction
SCALAdata scaling
PHENIXrefinement
SOLVEphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2015-06-15
  • Released Date: 2016-02-17
  • Deposition Author(s): Ha, N.C., Kim, J.S.

Revision History

  • Version 1.0: 2016-02-17
    Type: Initial release
  • Version 1.1: 2016-03-16
    Type: Database references
