5BUJ | pdb_00005buj

ERK2 complexed with a N-H tetrahydroazaindazole

• PDB DOI: https://doi.org/10.2210/pdb5BUJ/pdb

• Classification: Transferase/Transferase inhibitor
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2015-06-03 Released: 2015-07-15
• Deposition Author(s): Bellamacina, C.R., Shu, W., Bussiere, D.E., Bagdanoff, J.T.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:
  0.206 (Depositor), 0.207 (DCC)
• R-Value Work:
  0.171 (Depositor), 0.171 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Starting Model: other

Literature

Ligand efficient tetrahydro-pyrazolopyridines as inhibitors of ERK2 kinase.

Bagdanoff, J.T., Jain, R., Han, W., Poon, D., Lee, P.S., Bellamacina, C., Lindvall, M.

(2015) Bioorg Med Chem Lett 25: 3626-3629

• PubMed: 26144345
• DOI: https://doi.org/10.1016/j.bmcl.2015.06.063
• Primary Citation Related Structures:
  5BUE, 5BUI, 5BUJ


• PubMed Abstract:


  A series of structure based drug design hypotheses and focused screening efforts drove improvements in the potency and lipophilic efficiency of tetrahydro-pyrazolopyridine based ERK2 inhibitors. Elaboration of a fragment chemical lead established a new lipophilic aryl-Tyr interaction resulting in a substantial potency improvement. Subsequent cleavage of the lipophilic moiety led to reconfiguration of the ligand bound binding cleft. The reconfiguration established a polar contact between a newly liberated N-H and a vicinal Asp, resulting in further improvements in lipophilic efficiency and in vitro clearance.

---

Organizational Affiliation:
• Global Discovery Chemistry/Oncology and Exploratory Chemistry, Novartis Institutes for BioMedical Research, 250 Massachusetts Ave., Cambridge, MA 02139, USA. Electronic address: [e-mail].
Global Discovery Chemistry/Oncology and Exploratory Chemistry, Novartis Institutes for BioMedical Research, 4560 Horton St., Building 4, Emeryville, CA 94608, USA.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 41.76 kDa
• Atom Count: 3,097
• Modeled Residue Count: 331
• Deposited Residue Count: 361
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 1	A	361	Homo sapiens	Mutation(s): 0  Gene Names: MAPK1, ERK2, PRKM1, PRKM2 EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for P28482 (Homo sapiens) Explore P28482  Go to UniProtKB:  P28482
PHAROS:  P28482 GTEx:  ENSG00000100030

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
4VB	B [auth A]	4-[3-(pyridin-4-yl)-2,4,6,7-tetrahydro-5H-pyrazolo[4,3-c]pyridin-5-yl]pyridin-2(1H)-one C16 H15 N5 O ALNKCGBLFMOHAW-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:  0.206 (Depositor), 0.207 (DCC)
• R-Value Work:  0.171 (Depositor), 0.171 (DCC)
• R-Value Observed: 0.173 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 43.81	α = 90
b = 71.266	β = 90
c = 120.069	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
MOLREP	phasing
BUSTER	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2015-07-15
Deposition Author(s): Bellamacina, C.R., Shu, W., Bussiere, D.E., Bagdanoff, J.T.

Revision History

• Version 1.0: 2015-07-15
  Type: Initial release

• Version 1.1: 2015-08-12
  Changes: Database references
• Version 1.2: 2024-03-06
  Changes: Data collection, Database references, Derived calculations
• Version 1.3: 2026-03-04
  Changes: Refinement description, Structure summary
