5AZX

Crystal structure of p24delta1 GOLD domain (native 1)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.58 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.230

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

3D Structure and Interaction of p24 beta and p24 delta Golgi Dynamics Domains: Implication for p24 Complex Formation and Cargo Transport

Nagae, M.Hirata, T.Morita-Matsumoto, K.Theiler, R.Fujita, M.Kinoshita, T.Yamaguchi, Y.

(2016) J.Mol.Biol. 428: 4087-4099

  • DOI: 10.1016/j.jmb.2016.08.023
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The p24 family consists of four subfamilies (p24α, p24β, p24γ, and p24δ), and the proteins are thought to form hetero-oligomeric complexes for efficient transport of cargo proteins from the endoplasmic reticulum to the Golgi apparatus. The proteins p ...

    The p24 family consists of four subfamilies (p24α, p24β, p24γ, and p24δ), and the proteins are thought to form hetero-oligomeric complexes for efficient transport of cargo proteins from the endoplasmic reticulum to the Golgi apparatus. The proteins possess a conserved luminal Golgi dynamics (GOLD) domain, whose functions are largely unknown. Here, we present structural and biochemical studies of p24β1 and p24δ1 GOLD domains. Use of GOLD domain-deleted mutants revealed that the GOLD domain of p24δ1 is required for proper p24 hetero-oligomeric complex formation and efficient transport of GPI-anchored proteins. The p24β1 and p24δ1 GOLD domains share a common β-sandwich fold with a characteristic intrasheet disulfide bond. The GOLD domain of p24δ1 crystallized as dimers, allowing the analysis of a homophilic interaction site. Surface plasmon resonance and solution NMR analyses revealed that p24β1 and p24δ1 GOLD domains interact weakly (K d = ~10 -4 M). Bi-protein titration provided interaction site maps. We propose that the heterophilic interaction of p24 GOLD domains contributes to the formation of the p24 hetero-oligomeric complex and to efficient cargo transport.


    Organizational Affiliation

    Research Institute for Microbial Diseases and WPI Immunology Frontier Research Center, Osaka University, Suita, Osaka 565-0871, Japan; Key Laboratory of Carbohydrate Chemistry and Biotechnology, Ministry of Education, School of Biotechnology, Jiangnan University, Wuxi, Jiangsu 214122, China.,Research Institute for Microbial Diseases and WPI Immunology Frontier Research Center, Osaka University, Suita, Osaka 565-0871, Japan.,Structural Glycobiology Team, Systems Glycobiology Research Group, RIKEN-Max Planck Joint Research Center, RIKEN Global Research Cluster, 2-1 Hirosawa, Wako City, Saitama 351-0198, Japan. Electronic address: yyoshiki@riken.jp.,Structural Glycobiology Team, Systems Glycobiology Research Group, RIKEN-Max Planck Joint Research Center, RIKEN Global Research Cluster, 2-1 Hirosawa, Wako City, Saitama 351-0198, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Transmembrane emp24 domain-containing protein 10
A, B, C, D
103Rattus norvegicusMutation(s): 0
Gene Names: Tmed10 (Tmp21)
Find proteins for Q63584 (Rattus norvegicus)
Go to UniProtKB:  Q63584
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, D
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.58 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.230
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 68.232α = 90.00
b = 74.392β = 90.00
c = 79.890γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data scaling
PHENIXphasing
PHENIXrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
MEXTJapan25121738

Revision History

  • Version 1.0: 2016-09-14
    Type: Initial release
  • Version 1.1: 2016-10-19
    Type: Database references
