5A5J | pdb_00005a5j

Cytochrome 2C9 P450 inhibitor complex

• PDB DOI: https://doi.org/10.2210/pdb5A5J/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2015-06-18 Released: 2016-08-03
• Deposition Author(s): Skerratt, S.E., de Groot, M.J., Phillips, C.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.90 Å
• R-Value Free:
  0.288 (Depositor), 0.310 (DCC)
• R-Value Work:
  0.213 (Depositor), 0.230 (DCC)
• R-Value Observed:
  0.217 (Depositor)

Literature

Discovery of a Novel Binding Pocket for Cyp 2C9 Inhibitors: Crystallography, Pharmacophore Modelling and Inhibitor Sar.

Skerratt, S.E., De Groot, M.J., Phillips, C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 55.38 kDa
• Atom Count: 3,717
• Modelled Residue Count: 455
• Deposited Residue Count: 477
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CYTOCHROME P450 2C9	A	477	Homo sapiens	Mutation(s): 0  EC: 1.14.99.38 (PDB Primary Data), 1.14.14.1 (UniProt), 1.14.14.53 (UniProt), 1.14.14.52 (UniProt), 1.14.14.51 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P11712 (Homo sapiens) Explore P11712  Go to UniProtKB:  P11712
PHAROS:  P11712 GTEx:  ENSG00000138109

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	B [auth A]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
6YF	C [auth A]	N-[4-(3-chloranyl-4-cyano-phenoxy)-3,5-dimethoxy-phenyl]-1,1,1-tris(fluoranyl)methanesulfonamide C16 H12 Cl F3 N2 O5 S LUIIPCXBEHYHFN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.90 Å
• R-Value Free:  0.288 (Depositor), 0.310 (DCC)
• R-Value Work:  0.213 (Depositor), 0.230 (DCC)
• R-Value Observed: 0.217 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.29	α = 90
b = 91.29	β = 90
c = 169.37	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2016-08-03
Deposition Author(s): Skerratt, S.E., de Groot, M.J., Phillips, C.

Revision History

• Version 1.0: 2016-08-03
  Type: Initial release

• Version 1.1: 2024-05-08
  Changes: Data collection, Database references, Derived calculations, Other
