Structure of unbound MERS-CoV spike receptor-binding domain (England1 strain).

Experimental Data Snapshot

  • Resolution: 3.02 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.217
  • R-Value Observed: 0.220

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history


Evaluation of candidate vaccine approaches for MERS-CoV.

Wang, L.Shi, W.Joyce, M.G.Modjarrad, K.Zhang, Y.Leung, K.Lees, C.R.Zhou, T.Yassine, H.M.Kanekiyo, M.Yang, Z.Y.Chen, X.Becker, M.M.Freeman, M.Vogel, L.Johnson, J.C.Olinger, G.Todd, J.P.Bagci, U.Solomon, J.Mollura, D.J.Hensley, L.Jahrling, P.Denison, M.R.Rao, S.S.Subbarao, K.Kwong, P.D.Mascola, J.R.Kong, W.P.Graham, B.S.

(2015) Nat Commun 6: 7712-7712

  • DOI: https://doi.org/10.1038/ncomms8712
  • Primary Citation of Related Structures:
    4ZPT, 4ZPV, 4ZPW

  • PubMed Abstract:

    The emergence of Middle East respiratory syndrome coronavirus (MERS-CoV) as a cause of severe respiratory disease highlights the need for effective approaches to CoV vaccine development. Efforts focused solely on the receptor-binding domain (RBD) of the viral Spike (S) glycoprotein may not optimize neutralizing antibody (NAb) responses. Here we show that immunogens based on full-length S DNA and S1 subunit protein elicit robust serum-neutralizing activity against several MERS-CoV strains in mice and non-human primates. Serological analysis and isolation of murine monoclonal antibodies revealed that immunization elicits NAbs to RBD and, non-RBD portions of S1 and S2 subunit. Multiple neutralization mechanisms were demonstrated by solving the atomic structure of a NAb-RBD complex, through sequencing of neutralization escape viruses and by constructing MERS-CoV S variants for serological assays. Immunization of rhesus macaques confers protection against MERS-CoV-induced radiographic pneumonia, as assessed using computerized tomography, supporting this strategy as a promising approach for MERS-CoV vaccine development.

  • Organizational Affiliation

    Emerging Respiratory Viruses Section, Laboratory of Infectious Diseases, National Institute of Allergy and Infectious Diseases, National Institutes of Health, Bethesda, Maryland 20892, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Spike glycoproteinA [auth R],
B [auth S]
208Betacoronavirus England 1Mutation(s): 0
Gene Names: S3
Find proteins for K9N5Q8 (Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012))
Explore K9N5Q8
Go to UniProtKB:  K9N5Q8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupK9N5Q8
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 3.02 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.217
  • R-Value Observed: 0.220
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.667α = 90
b = 109.887β = 90
c = 125.279γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-08-12
    Type: Initial release
  • Version 1.1: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
