Crystal structure of the in-line aligned env22 twister ribozyme

Experimental Data Snapshot

  • Resolution: 2.89 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.177
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report

This is version 1.0 of the entry. See complete history


In-line alignment and Mg(2+) coordination at the cleavage site of the env22 twister ribozyme.

Ren, A.Kosutic, M.Rajashankar, K.R.Frener, M.Santner, T.Westhof, E.Micura, R.Patel, D.J.

(2014) Nat Commun 5: 5534-5534

  • DOI: https://doi.org/10.1038/ncomms6534
  • Primary Citation of Related Structures:
    4RGE, 4RGF

  • PubMed Abstract:

    Small self-cleaving nucleolytic ribozymes contain catalytic domains that accelerate site-specific cleavage/ligation of phosphodiester backbones. We report on the 2.9-Å crystal structure of the env22 twister ribozyme, which adopts a compact tertiary fold stabilized by co-helical stacking, double-pseudoknot formation and long-range pairing interactions. The U-A cleavage site adopts a splayed-apart conformation with the modelled 2'-O of U positioned for in-line attack on the adjacent to-be-cleaved P-O5' bond. Both an invariant guanosine and a Mg(2+) are directly coordinated to the non-bridging phosphate oxygens at the U-A cleavage step, with the former positioned to contribute to catalysis and the latter to structural integrity. The impact of key mutations on cleavage activity identified an invariant guanosine that contributes to catalysis. Our structure of the in-line aligned env22 twister ribozyme is compared with two recently reported twister ribozymes structures, which adopt similar global folds, but differ in conformational features around the cleavage site.

  • Organizational Affiliation

    Structural Biology Program, Memorial Sloan-Kettering Cancer Center, New York, New York 10065, USA.

Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
env22 twister ribozyme
A, B, C
56synthetic construct
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on MG

Download Ideal Coordinates CCD File
AA [auth C]
BA [auth C]
CA [auth C]
D [auth A]
DA [auth C]
AA [auth C],
BA [auth C],
CA [auth C],
D [auth A],
DA [auth C],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth B],
O [auth B],
P [auth B],
Q [auth B],
R [auth B],
S [auth B],
T [auth B],
U [auth B],
V [auth C],
W [auth C],
X [auth C],
Y [auth C],
Z [auth C]
Experimental Data & Validation

Experimental Data

  • Resolution: 2.89 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.177
  • R-Value Observed: 0.180
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.071α = 90
b = 64.071β = 90
c = 578.773γ = 120
Software Package:
Software NamePurpose
XDSdata scaling
XDSdata reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-12-03
    Type: Initial release
