 4R0G | pdb_00004r0g

Crystal structure of Lpg0393 from Legionella pneumophila

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.269 (Depositor), 0.270 (DCC)
  • R-Value Work:
    0.222 (Depositor), 0.223 (DCC)
  • R-Value Observed:
    0.224 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4R0G

This is version 1.1 of the entry. See complete history.

Literature

Lpg0393 of Legionella pneumophila Is a Guanine-Nucleotide Exchange Factor for Rab5, Rab21 and Rab22

Sohn, Y.S., Shin, H.C., Park, W.S., Ge, J., Kim, C.H., Lee, B.L., Heo, W.D., Jung, J.U., Rigden, D.J., Oh, B.H.

(2015) PLoS One 10: e0118683-e0118683

  • DOI: https://doi.org/10.1371/journal.pone.0118683
  • Primary Citation Related Structures:
    4R0G

  • PubMed Abstract:

    Legionella pneumophila, a human intracellular pathogen, encodes about 290 effector proteins that are translocated into host cells through a secretion machinery. Some of these proteins have been shown to manipulate or subvert cellular processes during infection, but functional roles of a majority of them remain unknown. Lpg0393 is a newly identified Legionella effector classified as a hypothetical protein. Through X-ray crystallographic analysis, we show that Lpg0393 contains a Vps9-like domain, which is structurally most similar to the catalytic core of human Rabex-5 that activates the endosomal Rab proteins Rab5, Rab21 and Rab22. Consistently, Lpg0393 exhibited a guanine-nucleotide exchange factor activity toward the endosomal Rabs. This work identifies the first example of a bacterial guanine-nucleotide exchange factor that is active towards the Rab5 sub-cluster members, implying that the activation of these Rab proteins might be advantageous for the intracellular survival of Legionella.

    • Organizational Affiliation:
    • Department of Biological Sciences, KAIST Institute for the Biocentury, Cancer Metastasis Control Center, Korea Advanced Institute of Science and Technology, Daejeon, 305-701, Korea.

Macromolecule Content

  • Total Structure Weight: 133.83 kDa
  • Atom Count: 8,043
  • Modeled Residue Count: 995
  • Deposited Residue Count: 1,148
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Uncharacterized protein
A, B, C, D
287Legionella pneumophila subsp. pneumophila str. Philadelphia 1Mutation(s): 0
Gene Names: lpg0393
UniProt
Find proteins for Q5ZYH9 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513))
Explore Q5ZYH9
Go to UniProtKB:  Q5ZYH9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5ZYH9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.269 (Depositor), 0.270 (DCC)
  • R-Value Work:  0.222 (Depositor), 0.223 (DCC)
  • R-Value Observed: 0.224 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.636α = 90
b = 111.706β = 90
c = 167.958γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SOLVEphasing
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXrefinement

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-04-15
    Type: Initial release
  • Version 1.1: 2024-03-20
    Changes: Data collection, Database references
