Structure-based protein engineering efforts on the scaffold of a monomeric triosephosphate isomerase yielding a sugar isomerase

Experimental Data Snapshot

  • Resolution: 1.55 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.173
  • R-Value Observed: 0.175

wwPDB Validation   3D Report Full Report

This is version 2.0 of the entry. See complete history


Crystal structures of two monomeric triosephosphate isomerase variants identified via a directed-evolution protocol selecting for L-arabinose isomerase activity.

Krause, M.Kiema, T.R.Neubauer, P.Wierenga, R.K.

(2016) Acta Crystallogr F Struct Biol Commun 72: 490-499

  • DOI: https://doi.org/10.1107/S2053230X16007548
  • Primary Citation of Related Structures:
    4PC8, 4PCF

  • PubMed Abstract:

    The crystal structures are described of two variants of A-TIM: Ma18 (2.7 Å resolution) and Ma21 (1.55 Å resolution). A-TIM is a monomeric loop-deletion variant of triosephosphate isomerase (TIM) which has lost the TIM catalytic properties. Ma18 and Ma21 were identified after extensive directed-evolution selection experiments using an Escherichia coli L-arabinose isomerase knockout strain expressing a randomly mutated A-TIM gene. These variants facilitate better growth of the Escherichia coli selection strain in medium supplemented with 40 mM L-arabinose. Ma18 and Ma21 differ from A-TIM by four and one point mutations, respectively. Ma18 and Ma21 are more stable proteins than A-TIM, as judged from CD melting experiments. Like A-TIM, both proteins are monomeric in solution. In the Ma18 crystal structure loop 6 is open and in the Ma21 crystal structure loop 6 is closed, being stabilized by a bound glycolate molecule. The crystal structures show only small differences in the active site compared with A-TIM. In the case of Ma21 it is observed that the point mutation (Q65L) contributes to small structural rearrangements near Asn11 of loop 1, which correlate with different ligand-binding properties such as a loss of citrate binding in the active site. The Ma21 structure also shows that its Leu65 side chain is involved in van der Waals interactions with neighbouring hydrophobic side-chain moieties, correlating with its increased stability. The experimental data suggest that the increased stability and solubility properties of Ma21 and Ma18 compared with A-TIM cause better growth of the selection strain when coexpressing Ma21 and Ma18 instead of A-TIM.

  • Organizational Affiliation

    Laboratory of Bioprocess Engineering, Department of Biotechnology, Technische Universität Berlin, Ackerstrasse 76, ACK 24, Berlin, Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ma21-TIM239Trypanosoma brucei bruceiMutation(s): 0
Gene Names: tim
Find proteins for P04789 (Trypanosoma brucei brucei)
Explore P04789
Go to UniProtKB:  P04789
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04789
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on GOA

Download Ideal Coordinates CCD File
C2 H4 O3
Experimental Data & Validation

Experimental Data

  • Resolution: 1.55 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.173
  • R-Value Observed: 0.175
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.62α = 90
b = 62.62β = 90
c = 136.01γ = 90
Software Package:
Software NamePurpose
Cootmodel building

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
EMBO Shorterm FellowshipGermanyASTF 188-2011
FEBS Shortterm FellowshipGermany--
Academy of FinlandFinland117874

Revision History  (Full details and data files)

  • Version 1.0: 2015-04-22
    Type: Initial release
  • Version 1.1: 2016-06-29
    Changes: Data collection, Database references
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection, Database references, Derived calculations
