Crystal Structure of NolR from Sinorhizobium fredii

Experimental Data Snapshot

  • Resolution: 2.64 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.203
  • R-Value Observed: 0.205

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Structural basis for regulation of rhizobial nodulation and symbiosis gene expression by the regulatory protein NolR.

Lee, S.G.Krishnan, H.B.Jez, J.M.

(2014) Proc Natl Acad Sci U S A 111: 6509-6514

  • DOI: https://doi.org/10.1073/pnas.1402243111
  • Primary Citation of Related Structures:
    4OMY, 4OMZ, 4ON0

  • PubMed Abstract:

    The symbiosis between rhizobial microbes and host plants involves the coordinated expression of multiple genes, which leads to nodule formation and nitrogen fixation. As part of the transcriptional machinery for nodulation and symbiosis across a range of Rhizobium, NolR serves as a global regulatory protein. Here, we present the X-ray crystal structures of NolR in the unliganded form and complexed with two different 22-base pair (bp) double-stranded operator sequences (oligos AT and AA). Structural and biochemical analysis of NolR reveals protein-DNA interactions with an asymmetric operator site and defines a mechanism for conformational switching of a key residue (Gln56) to accommodate variation in target DNA sequences from diverse rhizobial genes for nodulation and symbiosis. This conformational switching alters the energetic contributions to DNA binding without changes in affinity for the target sequence. Two possible models for the role of NolR in the regulation of different nodulation and symbiosis genes are proposed. To our knowledge, these studies provide the first structural insight on the regulation of genes involved in the agriculturally and ecologically important symbiosis of microbes and plants that leads to nodule formation and nitrogen fixation.

  • Organizational Affiliation

    Department of Biology, Washington University, St. Louis, MO 63130.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B, C, D, E
A, B, C, D, E, F, G, H
118Sinorhizobium frediiMutation(s): 0
Gene Names: nolR
Find proteins for Q83TD2 (Rhizobium fredii)
Explore Q83TD2
Go to UniProtKB:  Q83TD2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ83TD2
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on PO4

Download Ideal Coordinates CCD File
I [auth B]
J [auth B]
K [auth C]
L [auth C]
M [auth D]
I [auth B],
J [auth B],
K [auth C],
L [auth C],
M [auth D],
N [auth D],
O [auth E],
P [auth E],
Q [auth F],
R [auth F],
S [auth G],
T [auth G],
U [auth H],
V [auth H]
O4 P
Experimental Data & Validation

Experimental Data

  • Resolution: 2.64 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.203
  • R-Value Observed: 0.205
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.771α = 90
b = 99.619β = 90.08
c = 113.017γ = 90
Software Package:
Software NamePurpose
HKL-3000data collection
HKL-3000data reduction
HKL-3000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-04-16
    Type: Initial release
  • Version 1.1: 2014-06-04
    Changes: Database references
  • Version 1.2: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
