4JJU

Crystal structure of HCV NS5B polymerase in complex with COMPOUND 29

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.91 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.192

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history.


Literature

Structure-based design of novel HCV NS5B thumb pocket 2 allosteric inhibitors with submicromolar gt1 replicon potency: Discovery of a quinazolinone chemotype.

Beaulieu, P.L., Coulombe, R., Duan, J., Fazal, G., Godbout, C., Hucke, O., Jakalian, A., Joly, M.A., Lepage, O., Llinas-Brunet, M., Naud, J., Poirier, M., Rioux, N., Thavonekham, B., Kukolj, G., Stammers, T.A.

(2013) Bioorg Med Chem Lett 23: 4132-4140

  • DOI: 10.1016/j.bmcl.2013.05.037
  • Primary Citation of Related Structures:
    4JJS, 4JJU

  • PubMed Abstract:

    • We describe the structure-based design of a novel lead chemotype that binds to thumb pocket 2 of HCV NS5B polymerase and inhibits cell-based gt1 subgenomic reporter replicons at sub-micromolar concentrations (EC50<200nM). This new class of potent thumb pocket 2 inhibitors features a 1H-quinazolin-4-one scaffold derived from hybridization of a previously reported, low affinity thiazolone chemotype with our recently described anthranilic acid series ...

    We describe the structure-based design of a novel lead chemotype that binds to thumb pocket 2 of HCV NS5B polymerase and inhibits cell-based gt1 subgenomic reporter replicons at sub-micromolar concentrations (EC50<200nM). This new class of potent thumb pocket 2 inhibitors features a 1H-quinazolin-4-one scaffold derived from hybridization of a previously reported, low affinity thiazolone chemotype with our recently described anthranilic acid series. Guided by X-ray structural information, a key NS5B-ligand interaction involving the carboxylate group of anthranilic acid based inhibitors was replaced by a neutral two-point hydrogen bonding interaction between the quinazolinone scaffold and the protein backbone. The in vitro ADME and in vivo rat PK profile of representative analogs are also presented and provide areas for future optimization of this new class of HCV polymerase inhibitors.

    Organizational Affiliation:

    Medicinal Chemistry, Boehringer Ingelheim (Canada) Ltd, Research and Development, 2100 Cunard Street, Laval, Quebec H7S 2G5, Canada. resgeneral.lav@boehringer-ingelheim.com



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Genome polyproteinA, B576Hepatitis C virus isolate HC-J4Mutation(s): 0
Gene Names: NS5B
EC: 3.4.22 (PDB Primary Data), 3.4.21.98 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.6.4.13 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for O92972 (Hepatitis C virus genotype 1b (strain HC-J4))
Explore O92972
Go to UniProtKB:  O92972
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO92972
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
1MB
Query on 1MB
Download Ideal Coordinates CCD File
D [auth A],
H [auth B]		1-(2,4-difluorobenzyl)-6-{[3-(trifluoromethyl)pyridin-2-yl]oxy}quinazolin-4(1H)-one
C21 H12 F5 N3 O2
SWXDHFLZCMRYEP-UHFFFAOYSA-N		 Ligand Interaction
GOL
Query on GOL
Download Ideal Coordinates CCD File
C [auth A],
G [auth B]		GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N		 Ligand Interaction
MG
Query on MG
Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
I [auth B],
J [auth B]		MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N		 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
1MB PDBBind:  4JJU IC50: 510 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.91 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.192
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.07α = 90
b = 108.39β = 90
c = 134.88γ = 90
Software Package:
Software NamePurpose
CNXrefinement
XDSdata reduction
XDSdata scaling
CNXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

  • Deposited Date: 2013-03-08
  • Released Date: 2013-06-12
    • Deposition Author(s): Coulombe, R.

Revision History  (Full details and data files)

  • Version 1.0: 2013-06-12
    Type: Initial release
  • Version 1.1: 2013-07-10
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Refinement description
