4HV1 | pdb_00004hv1

Laser-induced microfragmentation of lysozyme crystals allows X-ray nanodiffraction characterization of individual domains (lb4)

• PDB DOI: https://doi.org/10.2210/pdb4HV1/pdb

• Classification: HYDROLASE
• Organism(s): Gallus gallus
• Mutation(s): No


• Deposited: 2012-11-05 Released: 2013-11-20
• Deposition Author(s): Pechkova, E., Belmonte, L., Riekel, C., Popov, D., Koenig, C., Nicolini, C.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.278 (Depositor), 0.280 (DCC)
• R-Value Work:
  0.193 (Depositor), 0.196 (DCC)
• R-Value Observed:
  0.197 (Depositor)

Literature

Laser-induced microfragmentation of lysozyme crystals allows X-ray nanodiffraction characterization of individual domains

Pechkova, E., Belmonte, L., Riekel, C., Popov, D., Koenig, C., Nicolini, C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 14.33 kDa
• Atom Count: 1,079
• Modeled Residue Count: 129
• Deposited Residue Count: 129
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysozyme C	A	129	Gallus gallus	Mutation(s): 0  Gene Names: LYZ EC: 3.2.1.17
UniProt
Find proteins for P00698 (Gallus gallus) Explore P00698  Go to UniProtKB:  P00698

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.278 (Depositor), 0.280 (DCC)
• R-Value Work:  0.193 (Depositor), 0.196 (DCC)
• R-Value Observed: 0.197 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.835	α = 90
b = 78.835	β = 90
c = 37.095	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
XSCALE	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-11-20
Deposition Author(s): Pechkova, E., Belmonte, L., Riekel, C., Popov, D., Koenig, C., Nicolini, C.

Revision History

• Version 1.0: 2013-11-20
  Type: Initial release

• Version 1.1: 2014-04-16
  Changes: Other
• Version 1.2: 2024-10-30
  Changes: Data collection, Database references, Structure summary
