4GES | pdb_00004ges

crystal structure of GFP-TYR151PYZ with an unnatural amino acid incorporation

PDB DOI: https://doi.org/10.2210/pdb4GES/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Aequorea victoria
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2012-08-02 Released: 2012-08-29
Deposition Author(s): Dong, J., Liu, X., Li, J., Wang, J., Gong, W.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.23 Å
R-Value Free:
0.188 (Depositor), 0.194 (DCC)
R-Value Work:
0.163 (Depositor), 0.170 (DCC)
R-Value Observed:
0.164 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4GES

This is version 2.0 of the entry. See complete history.

Literature

Genetic incorporation of a metal-chelating amino Acid as a probe for protein electron transfer.

Liu, X., Li, J., Dong, J., Hu, C., Gong, W., Wang, J.

(2012) Angew Chem Int Ed Engl 51: 10261-10265

PubMed: 22936654 Search on PubMed
DOI: https://doi.org/10.1002/anie.201204962
Primary Citation Related Structures:
4GES, 4GF6

Organizational Affiliation

Laboratory of Non-coding RNA, Institute of Biophysics, Chinese Academy of Sciences, 15 Datun Road, Chaoyang District, Beijing, 100101, China.

Macromolecule Content

Total Structure Weight: 27.88 kDa
Atom Count: 2,070
Modeled Residue Count: 230
Deposited Residue Count: 246
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Green fluorescent protein	A [auth B]	246	Aequorea victoria	Mutation(s): 3 Gene Names: GFP
UniProt
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P42212
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
0WZ Query on 0WZ	A [auth B]	L-PEPTIDE LINKING	C₁₂ H₁₃ N₃ O₃		TYR

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.23 Å
R-Value Free: 0.188 (Depositor), 0.194 (DCC)
R-Value Work: 0.163 (Depositor), 0.170 (DCC)
R-Value Observed: 0.164 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.717	α = 90
b = 50.809	β = 90
c = 62.364	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
CNS	refinement
HKL-2000	data collection
DENZO	data reduction
HKL-2000	data scaling
CNS	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-08-29

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2012-08-29
Type: Initial release
Version 1.1: 2012-10-24
Changes: Database references
Version 1.2: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.3: 2023-09-13
Changes: Data collection, Database references, Refinement description
Version 2.0: 2023-11-15
Changes: Atomic model, Data collection
