4G0A

Crystallographic Analysis of Rotavirus NSP2-RNA Complex Reveals Specific Recognition of 5'-GG Sequence for RTPase activity


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystallographic Analysis of Rotavirus NSP2-RNA Complex Reveals Specific Recognition of 5' GG Sequence for RTPase Activity.

Hu, L.Chow, D.C.Patton, J.T.Palzkill, T.Estes, M.K.Prasad, B.V.

(2012) J Virol 86: 10547-10557

  • DOI: 10.1128/JVI.01201-12
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Rotavirus nonstructural protein NSP2, a functional octamer, is critical for the formation of viroplasms, which are exclusive sites for replication and packaging of the segmented double-stranded RNA (dsRNA) rotavirus genome. As a component of replicat ...

    Rotavirus nonstructural protein NSP2, a functional octamer, is critical for the formation of viroplasms, which are exclusive sites for replication and packaging of the segmented double-stranded RNA (dsRNA) rotavirus genome. As a component of replication intermediates, NSP2 is also implicated in various replication-related activities. In addition to sequence-independent single-stranded RNA-binding and helix-destabilizing activities, NSP2 exhibits monomer-associated nucleoside and 5' RNA triphosphatase (NTPase/RTPase) activities that are mediated by a conserved H225 residue within a narrow enzymatic cleft. Lack of a 5' γ-phosphate is a common feature of the negative-strand RNA [(-)RNA] of the packaged dsRNA segments in rotavirus. Strikingly, all (-)RNAs (of group A rotaviruses) have a 5' GG dinucleotide sequence. As the only rotavirus protein with 5' RTPase activity, NSP2 is implicated in the removal of the γ-phosphate from the rotavirus (-)RNA. To understand how NSP2, despite its sequence-independent RNA-binding property, recognizes (-)RNA to hydrolyze the γ-phosphate within the catalytic cleft, we determined a crystal structure of NSP2 in complex with the 5' consensus sequence of minus-strand rotavirus RNA. Our studies show that the 5' GG of the bound oligoribonucleotide interacts extensively with highly conserved residues in the NSP2 enzymatic cleft. Although these residues provide GG-specific interactions, surface plasmon resonance studies suggest that the C-terminal helix and other basic residues outside the enzymatic cleft account for sequence-independent RNA binding of NSP2. A novel observation from our studies, which may have implications in viroplasm formation, is that the C-terminal helix of NSP2 exhibits two distinct conformations and engages in domain-swapping interactions, which result in the formation of NSP2 octamer chains.


    Organizational Affiliation

    Verna and Marrs McLean Department of Biochemistry and Molecular Biology, Baylor College of Medicine, Houston, Texas, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Non-structural protein 2
A, B, C, D
317Simian 11 rotavirus (serotype 3 / strain SA11-Ramig)Mutation(s): 0
EC: 3.6.4
Find proteins for Q03243 (Rotavirus A (strain RVA/SA11-Ramig/G3P[X]))
Go to UniProtKB:  Q03243
  • Find similar nucleic acids by: Sequence   |   Structure
Entity ID: 2
MoleculeChainsLengthOrganism
RNA (5'-R(P*GP*GP*U)-3')E, F,G,H3synthetic construct
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CL
Query on CL

Download CCD File
A, B, C, D
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
NA
Query on NA

Download CCD File
C
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.69α = 90
b = 107.69β = 90
c = 272.211γ = 120
Software Package:
Software NamePurpose
HKL-3000data collection
PHASERphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2012-07-09
  • Released Date: 2012-08-22
  • Deposition Author(s): Hu, L., Prasad, B.V.V.

Revision History

  • Version 1.0: 2012-08-22
    Type: Initial release
  • Version 1.1: 2012-08-29
    Changes: Derived calculations
  • Version 1.2: 2012-09-26
    Changes: Database references
