4Z6Y | pdb_00004z6y

Structure of the TBC1D7-TSC1 complex

PDB DOI: https://doi.org/10.2210/pdb4Z6Y/pdb

Classification: HYDROLASE INHIBITOR/PROTEIN BINDING
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2015-04-06 Released: 2016-04-20
Deposition Author(s): Gai, Z., Wu, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.81 Å
R-Value Free:
0.255 (Depositor), 0.253 (DCC)
R-Value Work:
0.206 (Depositor), 0.206 (DCC)
R-Value Observed:
0.209 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4Z6Y

This is version 1.1 of the entry. See complete history.

Literature

Structure of the TBC1D7-TSC1 complex

Gai, Z., Wu, G.

To be published.

Macromolecule Content

Total Structure Weight: 152.03 kDa
Atom Count: 10,471
Modeled Residue Count: 1,304
Deposited Residue Count: 1,316
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
TBC1 domain family member 7	A [auth B], C [auth G], E, G [auth A]	273	Homo sapiens	Mutation(s): 0 Gene Names: TBC1D7, TBC7, HSPC239
UniProt & NIH Common Fund Data Resources
Find proteins for Q9P0N9 (Homo sapiens) Explore Q9P0N9 Go to UniProtKB: Q9P0N9
PHAROS: Q9P0N9 GTEx: ENSG00000145979
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9P0N9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Hamartin	B [auth C], D [auth H], F, H [auth D]	56	Homo sapiens	Mutation(s): 0 Gene Names: TSC1, KIAA0243, TSC
UniProt & NIH Common Fund Data Resources
Find proteins for Q92574 (Homo sapiens) Explore Q92574 Go to UniProtKB: Q92574
PHAROS: Q92574 GTEx: ENSG00000165699
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q92574
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.81 Å
R-Value Free: 0.255 (Depositor), 0.253 (DCC)
R-Value Work: 0.206 (Depositor), 0.206 (DCC)
R-Value Observed: 0.209 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.991	α = 90
b = 145.689	β = 89.65
c = 114.758	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-04-20

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2016-04-20
Type: Initial release
Version 1.1: 2024-10-23
Changes: Data collection, Database references, Derived calculations, Structure summary
