Crystal Structure of the Methionine Binding Protein, MetQ

Experimental Data Snapshot

  • Resolution: 1.60 Å
  • R-Value Free: 0.183
  • R-Value Work: 0.154
  • R-Value Observed: 0.156

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


The contribution of methionine to the stability of the Escherichia coli MetNIQ ABC transporter-substrate binding protein complex.

Nguyen, P.T.Li, Q.W.Kadaba, N.S.Lai, J.Y.Yang, J.G.Rees, D.C.

(2015) Biol Chem 396: 1127-1134

  • DOI: https://doi.org/10.1515/hsz-2015-0131
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Despite the ubiquitous role of ATP-binding cassette (ABC) importers in nutrient uptake, only the Escherichia coli maltose and vitamin B12 ABC transporters have been structurally characterized in multiple conformations relevant to the alternating access transport mechanism. To complement our previous structure determination of the E. coli MetNI methionine importer in the inward facing conformation (Kadaba et al. (2008) Science 321, 250-253), we have explored conditions stabilizing the outward facing conformation. Using two variants, the Walker B E166Q mutation with ATP+EDTA to stabilize MetNI in the ATP-bound conformation and the N229A variant of the binding protein MetQ, shown in this work to disrupt methionine binding, a high affinity MetNIQ complex was formed with a dissociation constant measured to be 27 nm. Using wild type MetQ containing a co-purified methionine (for which the crystal structure is reported at 1.6 Å resolution), the dissociation constant for complex formation with MetNI is measured to be ∼40-fold weaker, indicating that complex formation lowers the affinity of MetQ for methionine by this amount. Preparation of a stable MetNIQ complex is an essential step towards the crystallographic analysis of the outward facing conformation, a key intermediate in the uptake of methionine by this transport system.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
D-methionine-binding lipoprotein MetQA [auth X]279Escherichia coli K-12Mutation(s): 0
Gene Names: metQyaeCb0197JW0193
Find proteins for P28635 (Escherichia coli (strain K12))
Explore P28635
Go to UniProtKB:  P28635
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28635
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on MET

Download Ideal Coordinates CCD File
C5 H11 N O2 S
Experimental Data & Validation

Experimental Data

  • Resolution: 1.60 Å
  • R-Value Free: 0.183
  • R-Value Work: 0.154
  • R-Value Observed: 0.156
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.65α = 90
b = 87.37β = 90
c = 112.9γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PDB_EXTRACTdata extraction
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-04-08
    Type: Initial release
  • Version 1.1: 2015-09-23
    Changes: Database references
  • Version 1.2: 2017-09-27
    Changes: Author supporting evidence, Derived calculations, Refinement description
  • Version 1.3: 2023-09-27
    Changes: Data collection, Database references, Refinement description
