4XSQ

Structure of a variable lymphocyte receptor-like protein Bf66946 from Branchiostoma floridae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.79 Å
  • R-Value Free: 0.202
  • R-Value Work: 0.178
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structure of a variable lymphocyte receptor-like protein from the amphioxus Branchiostoma floridae.

Cao, D.D.Liao, X.Cheng, W.Jiang, Y.L.Wang, W.J.Li, Q.Chen, J.Y.Chen, Y.Zhou, C.Z.

(2016) Sci Rep 6: 19951-19951

  • DOI: https://doi.org/10.1038/srep19951
  • Primary Citation of Related Structures:
    4XSQ

  • PubMed Abstract:

    Discovery of variable lymphocyte receptors (VLRs) in agnathans (jawless fish) has brought the origin of adaptive immunity system (AIS) forward to 500 million years ago accompanying with the emergence of vertebrates. Previous findings indicated that amphioxus, a representative model organism of chordate, also possesses some homologs of the basic components of TCR/BCR-based AIS, but it remains unknown if there exist any components of VLR-based AIS in amphioxus. Bioinformatics analyses revealed the amphioxus Branchiostoma floridae encodes a group of putative VLR-like proteins. Here we reported the 1.79 Å crystal structure of Bf66946, which forms a crescent-shaped structure of five leucine-rich repeats (LRRs). Structural comparisons indicated that Bf66946 resembles the lamprey VLRC. Further electrostatic potential analyses showed a negatively-charged patch at the concave of LRR solenoid structure that might be responsible for antigen recognition. Site-directed mutagenesis combined with bacterial binding assays revealed that Bf66946 binds to the surface of Gram-positive bacteria Staphylococcus aureus and Streptococcus pneumonia via a couple of acidic residues at the concave. In addition, the closest homolog of Bf66946 is highly expressed in the potential immune organ gill of Branchiostoma belcheri. Altogether, our findings provide the first structural evidence for the emergence of VLR-like molecules in the basal chordates.


  • Organizational Affiliation

    Hefei National Laboratory for Physical Sciences at the Microscale and School of Life Sciences, University of Science and Technology of China, Hefei Anhui 230027, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
variable lymphocyte receptor-like protein Bf66946
A, B
183Branchiostoma floridaeMutation(s): 0
Gene Names: BRAFLDRAFT_66946
UniProt
Find proteins for C3YZ59 (Branchiostoma floridae)
Explore C3YZ59
Go to UniProtKB:  C3YZ59
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC3YZ59
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.79 Å
  • R-Value Free: 0.202
  • R-Value Work: 0.178
  • R-Value Observed: 0.180
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.25α = 90
b = 67.868β = 90
c = 118.041γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data processing
HKL-2000data scaling
PHENIXphasing
HKL-2000data reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-03-23
    Type: Initial release
