4XHN | pdb_00004xhn

Bacillus thuringiensis ParM with AMPPNP

PDB DOI: https://doi.org/10.2210/pdb4XHN/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Bacillus thuringiensis serovar kurstaki str. YBT-1520
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2015-01-06 Released: 2016-03-09
Deposition Author(s): Jiang, S.M., Robinson, R.C.
Funding Organization(s): Agency for Science, Technology and Research (A*STAR)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.272 (Depositor), 0.217 (DCC)
R-Value Work:
0.209 (Depositor), 0.218 (DCC)
R-Value Observed:
0.215 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4XHN

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

A novel plasmid-segregating actin-like protein from Bacillus thuringiensis forms dynamically unstable tubules

Jiang, S.M., Narita, A., Popp, D., Ghoshdastider, U., Lee, L.J., Srinivasan, R., Balasubramanian, M.K., Oda, T., Koh, F.J., Larsson, M., Robinson, R.C.

To be published.

Macromolecule Content

Total Structure Weight: 48.01 kDa
Atom Count: 2,927
Modeled Residue Count: 358
Deposited Residue Count: 423
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A	423	Bacillus thuringiensis serovar kurstaki str. YBT-1520	Mutation(s): 2 Gene Names: YBT1520_33546

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ANP Query on ANP Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C₁₀ H₁₇ N₆ O₁₂ P₃ PVKSNHVPLWYQGJ-KQYNXXCUSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.272 (Depositor), 0.217 (DCC)
R-Value Work: 0.209 (Depositor), 0.218 (DCC)
R-Value Observed: 0.215 (Depositor)

Space Group: P 2 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.443	α = 90
b = 71.412	β = 90
c = 114.094	γ = 90

Software Package:

Software Name	Purpose
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2016-03-09

Deposition Author(s):

Funding Organization	Location	Grant Number
Agency for Science, Technology and Research (A*STAR)	Singapore	12302FG012

Revision History (Full details and data files)

Version 1.0: 2016-03-09
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection, Database references, Derived calculations
