4X2W

Crystal structure of the Murine Norovirus NS6 protease (inactive C139A mutant) with a C-terminal extension to include residues P1 prime - P2 prime of NS7


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.302
  • R-Value Work: 0.254

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structure determination of Murine Norovirus NS6 proteases with C-terminal extensions designed to probe protease-substrate interactions.

Fernandes, H.Leen, E.N.Cromwell, H.Pfeil, M.P.Curry, S.

(2015) Peerj 3: e798-e798

  • DOI: 10.7717/peerj.798
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Noroviruses are positive-sense single-stranded RNA viruses. They encode an NS6 protease that cleaves a viral polyprotein at specific sites to produce mature viral proteins. In an earlier study we obtained crystals of murine norovirus (MNV) NS6 protea ...

    Noroviruses are positive-sense single-stranded RNA viruses. They encode an NS6 protease that cleaves a viral polyprotein at specific sites to produce mature viral proteins. In an earlier study we obtained crystals of murine norovirus (MNV) NS6 protease in which crystal contacts were mediated by specific insertion of the C-terminus of one protein (which contains residues P5-P1 of the NS6-7 cleavage junction) into the peptide binding site of an adjacent molecule, forming an adventitious protease-product complex. We sought to reproduce this crystal form to investigate protease-substrate complexes by extending the C-terminus of NS6 construct to include residues on the C-terminal (P') side of the cleavage junction. We report the crystallization and crystal structure determination of inactive mutants of murine norovirus NS6 protease with C-terminal extensions of one, two and four residues from the N-terminus of the adjacent NS7 protein (NS6 1', NS6 2', NS6 4'). We also determined the structure of a chimeric extended NS6 protease in which the P4-P4' sequence of the NS6-7 cleavage site was replaced with the corresponding sequence from the NS2-3 cleavage junction (NS6 4' 2|3).The constructs NS6 1' and NS6 2' yielded crystals that diffracted anisotropically. We found that, although the uncorrected data could be phased by molecular replacement, refinement of the structures stalled unless the data were ellipsoidally truncated and corrected with anisotropic B-factors. These corrections significantly improved phasing by molecular replacement and subsequent refinement.The refined structures of all four extended NS6 proteases are very similar in structure to the mature MNV NS6-and in one case reveal additional details of a surface loop. Although the packing arrangement observed showed some similarities to those observed in the adventitious protease-product crystals reported previously, in no case were specific protease-substrate interactions observed.


    Related Citations:
    • Structure of a murine norovirus NS6 protease-product complex revealed by adventitious crystallisation.
      Leen, E.N.,Baeza, G.,Curry, S.
      (2012) PLoS ONE 7: e38723


    Organizational Affiliation

    Department of Life Sciences, Imperial College London , UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
NS6 Protease
A, B
179Murine norovirus 1Mutation(s): 1
Find proteins for Q80J95 (Murine norovirus 1)
Go to UniProtKB:  Q80J95
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.302
  • R-Value Work: 0.254
  • Space Group: P 61 2 2
Unit Cell:
Length (Å)Angle (°)
a = 135.940α = 90.00
b = 135.940β = 90.00
c = 82.380γ = 120.00
Software Package:
Software NamePurpose
PHASERphasing
PDB_EXTRACTdata extraction
MOSFLMdata reduction
SCALAdata scaling
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-02-18
    Type: Initial release
  • Version 1.1: 2015-02-25
    Type: Database references
  • Version 1.2: 2015-03-18
    Type: Database references
