4X2S

Crystal structure of 276S/M395R-GltPh in inward-facing conformation


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.21 Å
  • R-Value Free: 0.314
  • R-Value Work: 0.278

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Transport domain unlocking sets the uptake rate of an aspartate transporter.

Akyuz, N.Georgieva, E.R.Zhou, Z.Stolzenberg, S.Cuendet, M.A.Khelashvili, G.Altman, R.B.Terry, D.S.Freed, J.H.Weinstein, H.Boudker, O.Blanchard, S.C.

(2015) Nature 518: 68-73

  • DOI: 10.1038/nature14158

  • PubMed Abstract:
  • Glutamate transporters terminate neurotransmission by clearing synaptically released glutamate from the extracellular space, allowing repeated rounds of signalling and preventing glutamate-mediated excitotoxicity. Crystallographic studies of a glutam ...

    Glutamate transporters terminate neurotransmission by clearing synaptically released glutamate from the extracellular space, allowing repeated rounds of signalling and preventing glutamate-mediated excitotoxicity. Crystallographic studies of a glutamate transporter homologue from the archaeon Pyrococcus horikoshii, GltPh, showed that distinct transport domains translocate substrates into the cytoplasm by moving across the membrane within a central trimerization scaffold. Here we report direct observations of these 'elevator-like' transport domain motions in the context of reconstituted proteoliposomes and physiological ion gradients using single-molecule fluorescence resonance energy transfer (smFRET) imaging. We show that GltPh bearing two mutations introduced to impart characteristics of the human transporter exhibits markedly increased transport domain dynamics, which parallels an increased rate of substrate transport, thereby establishing a direct temporal relationship between transport domain motion and substrate uptake. Crystallographic and computational investigations corroborated these findings by revealing that the 'humanizing' mutations favour structurally 'unlocked' intermediate states in the transport cycle exhibiting increased solvent occupancy at the interface between the transport domain and the trimeric scaffold.


    Organizational Affiliation

    1] National Biomedical Center for Advanced ESR Technology, Cornell University, Ithaca, New York 14853, USA [2] Department of Chemistry and Chemical Biology, Cornell University, Ithaca, New York 14853, USA.,1] Department of Physiology and Biophysics, Weill Cornell Medical College, Cornell University, 1300 York Avenue, New York, New York 10065, USA [2] Tri-Institutional Training Program in Chemical Biology, 445 East 69th Street, New York, New York 10065, USA.,Department of Physiology and Biophysics, Weill Cornell Medical College, Cornell University, 1300 York Avenue, New York, New York 10065, USA.,1] Department of Physiology and Biophysics, Weill Cornell Medical College, Cornell University, 1300 York Avenue, New York, New York 10065, USA [2] Swiss Institute of Bioinformatics, Quartier Sorge - Batiment Genopode, 1015 Lausanne, Switzerland.,1] Department of Physiology and Biophysics, Weill Cornell Medical College, Cornell University, 1300 York Avenue, New York, New York 10065, USA [2] HRH Prince Alwaleed Bin Talal Bin Abdulaziz Alsaud Institute for Computational Biomedicine, Weill Cornell Medical College, Cornell University, 1305 York Avenue, New York, New York 10065, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
425aa long hypothetical proton glutamate symport protein
A, B, C
422Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3)Mutation(s): 11
Membrane protein
mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Amino Acid Secondary Transporters
Protein:
Glutamate Transporter Homologue (GltPh)
Find proteins for O59010 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3))
Go to UniProtKB:  O59010
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A, B, C
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
ASP
Query on ASP

Download SDF File
Download CCD File
A, B, C
ASPARTIC ACID
C4 H7 N O4
CKLJMWTZIZZHCS-REOHCLBHSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.21 Å
  • R-Value Free: 0.314
  • R-Value Work: 0.278
  • Space Group: P 65 2 2
Unit Cell:
Length (Å)Angle (°)
a = 121.651α = 90.00
b = 121.651β = 90.00
c = 578.699γ = 120.00
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2014-11-26
  • Released Date: 2015-02-04
  • Deposition Author(s): Akyuz, N., Boudker, O.

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical SciencesUnited States5U54GM087519

Revision History

  • Version 1.0: 2015-02-04
    Type: Initial release
  • Version 1.1: 2017-09-13
    Type: Author supporting evidence, Derived calculations, Source and taxonomy
  • Version 1.2: 2018-04-25
    Type: Data collection, Database references, Source and taxonomy
